Marine Lighting Equipment
The marine lighting equipment is an essential lighting device specifically designed for illuminating ships as they traverse the Suez Canal and other narrow sea – routes during nighttime navigation. This powerful search light is capable of detecting and brightly illuminating obstacles on the water’s surface, ensuring safe passage through these critical waterways.
Product Characteristics
- Premium Material Construction: The lamp body is crafted from high – quality aluminum alloy, which not only makes it lightweight but also highly durable. It is paired with a top – notch toughened glass lampshade that can withstand the harsh marine environment, providing clear and unobstructed light emission.
- Dual – Bulb Design with Easy Switching: The search light features a two – bulb structure. Inside, there is a rotary switch that allows for seamless switching between the bulbs while the light is still powered on. This ensures continuous illumination even if one bulb fails, enhancing the reliability of the lighting system during critical navigation periods.
- Adjustable Hemisphere Reflectors: It is equipped with two hemisphere reflectors that can be horizontally adjusted within a range of ± 5°. This adjustability enables users to fine – tune the reflect effect, optimizing the light distribution according to specific navigation requirements and environmental conditions.
- Safe Vent – Valve for Pressure Balance: A safe vent – valve is installed beneath the lamp canister. This valve plays a crucial role in maintaining the air pressure balance inside and outside the lamp canister, preventing any potential damage caused by pressure differentials and ensuring the long – term functionality of the search light.
- Flexible Adjustment Capabilities: The lamp has a bending range of ± 30° and can be horizontally adjusted by ± 180°. This high degree of flexibility allows for precise positioning of the light beam, enabling it to cover a wide area and effectively illuminate obstacles in different directions during navigation.
- Parallel Light – Beam with Long – Range Illumination: The search light emits a parallel light – beam, which provides a far – reaching illumination distance. This feature is particularly important for detecting obstacles at a distance, giving ships ample time to take evasive actions and ensuring safe passage through the narrow Suez Canal and other sea – routes.
- Compliance with Industry Standards: It strictly conforms to the “GRADE ENTRY NORMS FOR STEEL SHIPS” and the requirements of the “SUEZ CANAL NAVIGATION RULES”. This compliance ensures that the search light meets the highest safety and performance standards set by the relevant authorities, making it a reliable choice for marine navigation in the Suez Canal and similar waterways.
Main Technical Parameters
| Product Name | Suez Canal Search Light |
|---|---|
| Voltage | 220V/50HZ, 220V/60HZ |
| Illuminant | Tungsten Halogen Light |
| Lamp Holder | GY16 |
| Power | 2000W |
| Luminous Flux | 53000lm |
| Irradiate Distance | ≥1800m |
| Protection Class | IP56 (providing excellent protection against dust and water jets, suitable for marine use) |
| Cable Outside Diameter | Φ14 – Φ16 |
| Weight | 29kg |
Attention please: The description was copied from different cooperating manufacturers. The description may be different with the goods, please check with us when order.
