MARINE LED CIRCULAR PENDANT LIGHT
Product Images and Dimensional Diagrams
[The image displays two types of LED circular pendant lights, CCD10 – 1L and CCD10 – 1D, each shown with a front – view photo and a side – view dimensional diagram. The diagrams include detailed measurements such as overall diameter, height, and other size – related specifications.]
Patents
- Invention Patent: ZL202430391719.2
- Utility Model Patent: ZL202421349476.1
Applicable Scope
Applied to the illumination for ship cabins, or the wet places such as ship decks, ship sidewalks.
CCD10 – 1L Specifications
| Item | Detail |
|---|---|
| Type | CCD10 – 1L |
| Rated Voltage | AC100 – 240V 50/60Hz |
| Power | 9W |
| Power Factor | ≥0.5 |
| Illuminant | LED Module |
| Color | White |
| Luminous Flux | 1100lm |
| Color Rendering Index | Ra≥80 |
| Color Temperature | 5000K (Optional: 3000K, 4000K, 5700K) |
| Protection Class | IP66 |
| Cable Outside Diameter | φ8 – φ12 (Optional: φ10 – φ14) |
| Installation Method | Suspension Type |
| Ambient Temperature | -25℃ – +55℃ |
| Lamp Body Material | Stainless Steel 304 |
| Lamp Shade Material | PC (Polycarbonate) |
| Weight | 2kg |
CCD10 – 1D Specifications
| Item | Detail |
|---|---|
| Type | CCD10 – 1D |
| Rated Voltage | AC100 – 240V 50/60Hz |
| Power | 10W |
| Power Factor | ≥0.5 |
| Illuminant | LED Bulb |
| Color | White |
| Luminous Flux | 827lm |
| Color Rendering Index | / |
| Color Temperature | 6500K (Optional: 3000K, 4000K, 5000K) |
| Protection Class | IP23 |
| Cable Outside Diameter | φ8 – φ12 (Optional: φ10 – φ14) |
| Installation Method | Suspension Type |
| Ambient Temperature | -25℃ – +55℃ |
| Lamp Body Material | Brass |
| Lamp Shade Material | Glass |
| Weight | 1.8kg |
Attention please: The description may be different with the product, please contact us for quotation.
