MARINE EMERGENCY DOWNLIGHT
Product Images and Light – Distribution Diagram
[The image displays the JXQ – 6G emergency downlight from multiple angles: a front – view showing three different color options (white, chrome – plated, gold – plated), a side – view, and a light – distribution diagram. The light – distribution diagram includes angular measurements and relative illuminance values.]
Applicable Scope
Suitable for decorative emergency lighting in cabins, kitchens, bathrooms, and corridors of luxury cruise ships and ships.
Technical Specifications
| Item | Detail |
|---|---|
| Type | JXQ – 6G |
| Rated Voltage | AC85 – 265V 50/60Hz |
| Power | 6W |
| Power Factor | ≥0.6 |
| Illuminant | LED |
| Color | White (also available in chrome – plated and gold – plated) |
| Luminous Flux | 450lm |
| Color Rendering Index | Ra≥80 |
| Color Temperature | 3000K (Optional: 4000K, 5000K, 6500K) |
| Emergency Time | ≥180min |
| Emergency Mode | Battery – powered emergency lighting |
| Protection Class | IP44 |
| Installation Method | Recessed – mounted Type |
| Ambient Temperature | -20℃ – +50℃ |
| Lamp Body Material | High – quality aluminum alloy |
| Lamp Shade Material | PC (Polycarbonate) (Optional: glass) |
| Color | Milky White |
| Weight | 1.2kg |
Attention please: The description may be different with the product, please contact us for quotation.
