Marine Candescent Explosion-proof Light CFD Series
Remark: The series of light is flameproof, material is copper alloy or stainless steel alloy. CFD2a can be used safely and reliably in the place with explosive air mixture, with explosive matters IIA, IIB and temperature group T1-T3. CFD3 and CFD4 fits for in the place with 1-2 zone of explosive matter IIA, IIB, IIC.
CFD2a Explosion-proof Light
CFD3 Explosion-proof Light
CFD4c Explosion-proof Light
Specifications
| Type | Explosion-proof Mark | Rated Voltage (V) | Maximum Rated Power (W) | Lamp Holder Type | Protection Class | Explosion-proof Quality Certificate Number | Weight (kg) |
|---|---|---|---|---|---|---|---|
| CFD2a | Exd IIBT3 | 220 | 200 | E27 | IP55 | NLE03240 | 19 |
| CFD2a | Exd IIBT3 | 220 | 60 | E27 | IP55 | NLE03240 | 19 |
| CFD2a | Exd IIBT3 | 220 | 125 自镇流高压汞灯 | E27 | IP55 | NLE03240 | 19 |
| CFD3 | Exd IICT4 | 220 | 100 | E27 | IP55 | NLE03237 | 13.5 |
| CFD3 | Exd IICT4 | 110 | 100 | E27 | IP55 | NLE03237 | 13.5 |
| CFD3 | Exd IICT6 | 24 | 25 | E27 | IP55 | NLE03238 | 13.5 |
| CFD4c | Exd IICT4 | 220 | 100 | E27 | IP55 | NLE03239 | 10 |
| CFD4c | Exd IICT4 | 110 | 40 | E27 | IP55 | NLE03239 | 10 |
CFD5 Explosion-proof Light
CFD6 Explosion-proof Light
Specifications
| Type | Explosion-proof Mark | Rated Voltage (V) | Maximum Rated Power | Lamp Holder Type | Protection Class | Weight (kg) |
|---|---|---|---|---|---|---|
| CFD5-25 | ExdIICT6 | 110V/220V | 25W | E27 | IP56 | 5.0Kg |
| CFD5-40 | ExdIICT5 | 110V/220V | 40W | E27 | IP56 | 5.0Kg |
| CFD5-60 | ExdIICT4 | 110V/220V | 60W | E27 | IP56 | 5.0Kg |
| CFD6-60 | ExdIICT2 | 110V/220V | 60W | E27 | IP56 | 3.6Kg |
Remark: The lamp is apply to ship, petroleum exploration flat form, chemistry and 1 area or 2 area with explosive gas for lighting cast copper alloy body, stainless guard, with toughened transparent glass shield.
Note: The description may be different with the product, please contact us for quotation.
