LED Fluorescent Pendant Light
LED FLUORESCENT PENDANT LIGHT
- Product Image and Diagram: The image displays a LED fluorescent pendant light with a front – view photo and a technical diagram showing its dimensions (length L, and other detailed measurements like L1, H, etc.).
Main Technical Parameters
| Parameter | Description |
|---|---|
| The scope of application | Applied to dry cabins, such as the residence, rest room, dining room, cabin, operator of the sailors and passengers. |
| Light source type | LED |
| Model/Type | JCY21 – 2L, JCY21 – 2EFL, JCY41 – L, JCY41 – 2L, JCY41 – 2EFL |
| Voltage | 85 – 265V |
| Power | For JCY21 – 2L: 2X9W, 24V/3W; JCY21 – 2EFL: 2X18W; JCY41 – L: 2X18W; JCY41 – 2L: 2X18W; JCY41 – 2EFL: 24V/3W (power description in original is a bit messy, this is an organized presentation based on the text) |
| Lamp Luminous Flux | For JCY21 – 2L: 1350lm; for JCY21 – 2EFL: (not specified separately, but related to the model’s general spec); for JCY41 – 2EFL: 3100lm (and for other models not clearly separated in the original text, but we take these as key data points) |
| Color Temperature | 4000K, 6500K |
| Protection Class | IP67 |
| Cable Outside Diameter | Φ10 – Φ14 |
| Housing Material | Galvanized sheet |
| Lampshade Material | PC (Polycarbonate), and for some models with additional features, it may involve other materials as per the suffix description |
| Weight | JCY21 – 2L: 5.1KG; JCY21 – 2EFL: 6.6KG; JCY41 – L: 7.8KG; JCY41 – 2L: 8KG; JCY41 – 2EFL: 9.8KG |
Remarks
This lighting fixture, with the suffix “L” added to the model number, represents a configuration with a protective mesh cover; with the suffix “J”, it represents a configuration with a shock – absorbing device; with the suffix “G”, it represents a configuration with an additional emergency lighting device, with a continuous discharge of ≥3 hours. Adding “A” in the model means the body is made of stainless steel.
Attention please: The description may be different with the product, please contact us for quotation.
