Anchor Chain Fittings

Diameter (mm)	Common Link (kgs)	Enlarged Link (kgs)	End Link (kgs)	Joining Shackle Kenter (kgs)	Joining Shackle Type D (kgs)	Anchor Shackle Type D (kgs)	Swivel (kgs)	Swivel Shackle (kgs)
12.5	0.17	0.23	0.23	0.39	0.8	1.1	0.9	–
14	0.24	0.32	0.36	0.51	1.1	1.3	1.3	–
16	0.36	0.5	0.51	0.62	1.3	1.6	1.7	–
17.5	0.47	0.74	0.69	0.82	1.6	2	2.1	–
19	0.6	0.88	0.89	1	1.8	2.5	2.5	–
20.5	0.76	1.1	1.13	1.35	2.1	3.3	3.1	–
22	0.93	1.25	1.28	1.6	2.5	4	3.5	10
24	1.21	1.7	1.77	2	3.5	5	5	14
26	1.55	2.15	2.2	2.7	4.3	6	6	18
28	1.9	2.8	2.9	3.3	5	7.5	7.5	23
30	2.4	3.2	3.3	3.9	6	9.5	9	28
32	2.9	3.9	4	4.6	7.5	12	11	33
34	3.4	4.7	5	5.8	9.5	14	13.5	38
36	4	5.5	5.9	6.6	11	17	16	46
38	4.7	6.1	6.8	7.8	13	20	19	53
40	5.5	7.1	8	9.1	15	23	23	61
42	6.4	8.4	9.6	10.5	17.5	26	27	69
44	7.4	10	11.2	12.2	20	29	32	75
46	8.5	11.5	13	14	22.5	33	37	82
48	9.8	13.1	15	16	26	37	44	90
50	11	15	17	18	29	41	57	97
52	13	17	20	20	31	45	57	105
54	14	19	22	20	34	50	67	113
56	16	21	23	24	38	54	67	120
58	17	23	25	28	44	65	80	129
60	19	25	27	28	48	70	95	140
62	21	28	30	33	52	76	95	140
64	23	31	34	38	57	83	112	155
66	25	34	38	38	66	94	130	180
68	27	37	42	44	70	101	130	180
70	30	40	45	44	75	108	152	200
73	34	45	52	51	87	124	172	250
76	39	50	59	58	99	141	194	315
78	42	55	63	65	106	150	194	315
81	46	61	70	74	119	171	220	375
84	52	68	78	84	134	193	242	425
87	58	75	86	94	150	218	270	475
90	64	82	95	105	167	243	300	540
92	68	88	100	105	175	256	325	570
95	75	98	112	115	200	290	350	610
97	80	102	120	135	210	305	350	610
100	88	112	130	150	230	335	385	680
102	93	120	138	150	243	350	420	772
107	109	140	158	172	285	410	495	820
111	120	160	175	200	305	445	535	860
114	130	173	193	225	325	475	570	900
117	142	185	210	225	345	505	610	950
122	160	210	235	267	380	550	650	1000
127	182	239	260	318	420	600	720	1080
132	205	260	305	370	480	675	760	1150
137	230	285	330	390	550	750	900	1500
142	255	325	375	435	650	900	1100	1900

Note: The measurements are changed due to models. EZCX can not responsible for any deviations between this table and delivered products.

Note: The description may be different with the product, please contact us for quotation.
