16A Marine Brass Socket with Chain Switch
Product Images and Dimensional Diagrams
[The image displays three different models of 16A marine brass sockets with chain switches: CZELJ73 – 16/2, CZELJ10H – 16/2, and CZELJ10H – 16/3. For each model, there is a front – view photo, a side – view photo, and a detailed dimensional diagram showing various measurements such as length, diameter, and hole – spacing dimensions. Additionally, there is a close – up photo of the chain – switch mechanism for one of the models.]
Technical Specifications Table
| Item | CZELJ73 – 16/2 | CZELJ10H – 16/2 | CZELJ10H – 16/3 |
|---|---|---|---|
| Rated Current (Rated Current) | 16A | 16A | 16A |
| Rated Voltage (Rated Voltage) | AC250V | AC250V | AC250V |
| Protection Class (Protection Class) | IP56 | IP56 | IP56 |
| Cable Outer Diameter (Cable Outside Diameter) | Ø9 – Ø12 | Ø9 – Ø12 | Ø9 – Ø12 |
| Weight (Weight) | 1.2kg | 1.2kg | 1.3kg |
| Standard (Standard) | IEC – 60092 – 301, CB3411 – 1992 | IEC – 60092 – 301, CB3411 – 1992 | IEC – 60092 – 301, CB3411 – 1992 |
Attention please: The description may be different with the product, please contact us for quotation.
