SIGNAL LIGHTS CONTROLLER
Applicable Scope
The signal lights controller is applied to control and monitor the signal lights of ships. The controller has functions such as dimming, testing, and voice prompts, along with main – power auto – switching, main – power failure alarm, and signal – light failure alarm functions. The product meets the requirements of CCS’s “Rules for the Classification of Sea – going Steel Ships”, MSC.253(83)决议, IMO A.694(17) Resolution, and Statutory Instruments Rules for Ships and Offshore Facilities.
Product Features
- The control panel adopts LED indicator lights and button operations, simulating the actual ship layout to display the positions of the signal lights for easy observation and operation.
- The controller supports LED – type signal lights.
- The control panel has a sound – light alarm function for signal – light failures.
- The control panel has a dimming function.
- The controller has the function of automatically switching the main power supply and the standby power supply, as well as the function of alarming for main – power failures and signal – light failures.
- It has an external communication interface and VDR interface, and has an integrated alarm output interface.
- The control system is equipped with a lamp service – life timing function.
Electrical Parameters
- Rated Voltage: DC24V, AC110V/60Hz, AC220V/50Hz, AC230V/50Hz, AC240V/50Hz
- Controller Power: According to the requirements
- Output:
- Control Power: 100W/100W/Way
- Output Signal: Comprehensive alarm signal (normally open passive contact)
- Communication Interface: 1 CAN, 1 RS485 (complying with NMEA0183 requirement); 1 Way CAN, 1 Way RS485 (optional NMEA0183 requirement)
- Protection Grade: Control panel IP22, Control box IP44
Installation Method
The control panel adopts embedded installation, and the control box is installed in a cabinet or on a bridge console.
Ambient Temperature
-20°C ~ +55°C
