Ships’ Ordinary Rectangular Window – GB/T5746-1996
YHS-001
Application
Used for the rectangular window of superstructure above the freeboard deck and deck house. It meets ISO 3903:1993.
1. Series
| Series | Description |
|---|---|
| Common Series | Rectangular windows usually with side windows |
| Heating Series | Rectangular windows equipped with electric heating devices |
2. Type
| Type | Feature | Main Function |
|---|---|---|
| (as per series) | Heating series | Equipped with electric heating devices |
3. Nominal Dimensions
| Code | Nominal Size |
|---|---|
| 1 | 300 × 425 |
| 2 | 355 × 500 |
| 3 | 400 × 560 |
| 4 | 450 × 630 |
| 5 | 500 × 710 |
| 6 | 560 × 800 |
| 7 | 600 × 830 |
| 8 | 700 × 910 |
| 9 | 800 × 1000 |
4. Type Features
| Series | Type Feature | Main Function |
|---|---|---|
| Heating Series | Equipped with electric heating devices | Rectangular windows with heating |
5. Glass Thickness
(Note: The original table in the first image contained an extremely long, repetitive list of thickness values from 1.5 mm to over 100 mm. The following table presents the data in a summarized format based on the provided content.)
| Code | Glass Thickness (mm) |
|---|---|
| 1 | 1.5 |
| 2 | 2.5 |
| 3 | 3.5 |
| 4 | 4.5 |
| 5 | 5.5 |
| 6 | 6.5 |
| 7 | 7.5 |
| 8 | 8.5 |
| 9 | 9.5 |
| 10 | 10.5 |
| 11 | 11.5 |
| 12 | 12.5 |
| … | … (continues incrementally by 1.0 mm per code up to 173.5 mm) |
(For the complete list, refer to the original document.)
Additional Information (from second image)
-
Bolted Rectangular Window
-
Welded Rectangular Window
Model Reference
-
YH-S-001 – Ships’ Ordinary Rectangular Window – GB/T5746-1996
Note: The description may be different with the product, please contact us for quotation.
