China Medium Pressure Water-Cooled Ship’s Air Compressor HC Series: Efficient, Reliable, and Quiet Solution for Marine Applications
The China Medium Pressure Water-Cooled Ship’s Air Compressor HC Series is a direct-connection type, piston-driven compressor designed for second-stage compression. Utilizing water cooling technology, it efficiently operates with air bottles ranging from 1.0 m³ to 3.0 m³ in capacity, making it an ideal choice for various marine vessels.
Key Features:
- High Efficiency & Energy Saving: This air compressor is engineered to deliver optimal performance while minimizing energy consumption, reducing operational costs over time.
- Low Noise Operation: Designed with noise reduction in mind, it ensures a quieter working environment on board, enhancing crew comfort.
- Auto-Control Functionality: Equipped with a wall-hanging automatic control box, featuring an outer connection terminal for operating indication signals and comprehensive fault alarming signals. The automatic control system includes functions such as automatic starting, adjustable pressure settings (2 MPa), automatic stopping at 3 MPa, automatic unloading, low oil pressure (0.1 MPa) and low water pressure (0.02 MPa) alarms, ensuring safe and efficient operation.
Supply Scope:
- Air Compressor Unit: Includes a public base, air compressor, motor, hydraulic and oil pressure controllers, high and low-pressure unloading electromagnetic valves, and a cooling water inlet solenoid valve.
- Control Box: Comes with a manual and automatic change-over switch for versatile operation.
- Starting and Stopping Pressure Controller: Connects to the gas tank vent line for precise pressure management.
- Exhaust Hose and Outlet Flange: Conforms to GB10746, PN4.0, DN32 standards for reliable exhaust connections.
- Inlet Hose and Inlet Flange: Meets GB2501, PN0.6, DN20 specifications for secure inlet connections.
- Outlet Hose and Outlet Flange: Also follows GB2501, PN0.6, DN20 standards for consistent outlet performance.
- Random Spare Parts and Special Tools: Included to facilitate maintenance and repairs.
Technical Service:
- Installation Assistance: The buyer is responsible for installation, with the supplier providing necessary assistance.
- Commissioning Support: The supplier handles commissioning, with the buyer assisting and providing necessary protection. The supplier ensures an adequate supply of wearing parts.
Specifications:
| Model | Type | Displacement Capacity (m³/h) | Rated Pressure (Mpa) | Rotate Speed (r/min) | Motor Power (KW) | Weight (Kg) | Overall Size (mm) |
|---|---|---|---|---|---|---|---|
| HC-65A | Vertical type, Water cooling, Second stage compression, Piston type | 69 | 3 | 750 | 18.5 | 700 | 1430x900x1260 |
| 82 (440V) | 900 | 22 | |||||
| 90 | 960 | 22 | |||||
| HC-265A | Vertical type, Water cooling, Second stage compression, Piston type | 137 | 3 | 750 | 37 | 1400 | 1870x1000x1180 |
| 170 (440V) | 900 | 45 | |||||
| 190 | 960 | 45 |
FAQs:
- Q: What makes the HC Series air compressor suitable for marine applications?
- A: The HC Series air compressor is designed with water cooling and second-stage compression, making it highly efficient and reliable for the demanding conditions of marine environments. Its compact size and low noise operation also make it ideal for use on board various vessels.
- Q: Can the HC Series air compressor be customized for specific pressure requirements?
- A: Yes, the HC Series air compressor features an adjustable pressure setting (2 MPa), allowing for customization based on specific application needs. Additionally, the automatic control system ensures precise pressure management throughout operation.
- Q: What kind of maintenance is required for the HC Series air compressor?
- A: Regular maintenance includes checking oil and water levels, inspecting hoses and flanges for wear, and replacing wearing parts as needed. The supplier provides random spare parts and special tools to facilitate maintenance tasks.
- Q: How does the automatic control system enhance the safety and efficiency of the HC Series air compressor?
- A: The automatic control system includes functions such as automatic starting, stopping, and unloading, as well as low oil and water pressure alarms. These features ensure safe operation by preventing potential issues and optimizing performance, reducing the risk of downtime and costly repairs.
Please Note: The description might be incorrect, please contact us for confirmation.
