Portable Floodlight
Product Images and Dimensions
The image displays several variants of portable floodlights (TG32 – 50L to TG32 – 600L) from two different angles, along with detailed dimensional diagrams for each variant. The dimensions include height, width, and depth measurements for both the folded and unfolded (or different usage states) of the floodlights. For example, for the 50W variant, the folded dimensions are 15.8cm x 14cm x 10.2cm, and the unfolded dimensions are 26cm x 16cm x 14cm. Similar dimensional details are provided for all other power variants.
Main Technical Parameters
Scope of Application: Applied to projecting illumination in outdoor places such as ship, dock, port, storeplace and petroleum platform etc.
Product Specifications Table
| Specification | TG32 – 50L | TG32 – 100L | TG32 – 150L | TG32 – 200L | TG32 – 300L | TG32 – 450L | TG32 – 600L |
|---|---|---|---|---|---|---|---|
| Type | TG32 – 50L | TG32 – 100L | TG32 – 150L | TG32 – 200L | TG32 – 300L | TG32 – 450L | TG32 – 600L |
| Rated Voltage | AC110V/240V | AC110V/240V | AC110V/240V | AC110V/240V | AC110V/240V | AC110V/240V | AC110V/240V |
| Power | 50W | 100W | 150W | 200W | 300W | 450W | 600W |
| Illuminant | LED | LED | LED | LED | LED | LED | LED |
| Vertical Angle | Upside 90°, down 45° angle | Upside 90°, down 45° angle | Upside 90°, down 45° angle | Upside 90°, down 45° angle | Upside 90°, down 45° angle | Upside 90°, down 45° angle | Upside 90°, down 45° angle |
| Protection Class | IP67 | IP67 | IP67 | IP67 | IP67 | IP67 | IP67 |
| Lamp Body Material | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium | Aluminium |
| Lamp Shade Material | Tempered glass | Tempered glass | Tempered glass | Tempered glass | Tempered glass | Tempered glass | Tempered glass |
| Weight | 0.9KG | 1.6KG | 2.78KG | 4.04KG | 5.69KG | 8.4KG | 11.13KG |
Attention please: The description may be different with the product, please contact us for quotation.
