PENDANT LIGHT
Product Images and Technical Diagrams
[The image displays two types of pendant lights, JCL15 – 1 and JCL15 – 2, each shown with a front – view photo and a side – view photo, along with installation dimension diagrams. The diagrams include detailed measurements such as overall length, diameter, and mounting – related dimensions.]
Design Patent
Design Patent: ZL202230743216.2
Applicable Scope
Applicable for illumination in all kinds of places with water dripping, water splashing or water immersion in vessels, such as engine room, dry cargo hold, tunnel, pipeline, weather deck, etc.
JCL15 – 1 Specifications
| Item | Detail |
|---|---|
| Type | JCL15 – 1 |
| Rated Voltage | AC100 – 240V 50/60Hz |
| Power | 20W |
| Power Factor | ≥0.5 |
| Illuminant | LED |
| Color | White |
| Luminous Flux | 2200lm |
| Color Rendering Index | Ra≥80 |
| Color Temperature | 5700K (Optional: 3000K, 4000K, 5000K) |
| Protection Class | IP66/IP67 |
| Cable Outside Diameter | φ8 – φ12 (Optional: φ10 – φ14) |
| Installation Method | Suspension Type |
| Ambient Temperature | -30℃ – +55℃ |
| Lamp Body Material | Engineering Plastics PC |
| Gland Material | Brass |
| Lamp Shade Material | Toughened Glass |
| Weight | 2.0kg |
JCL15 – 2 Specifications
| Item | Detail |
|---|---|
| Type | JCL15 – 2 |
| Rated Voltage | AC100 – 240V 50/60Hz |
| Power | 40W |
| Power Factor | ≥0.5 |
| Illuminant | LED |
| Color | White |
| Luminous Flux | 4500lm |
| Color Rendering Index | Ra≥80 |
| Color Temperature | 5700K (Optional: 3000K, 4000K, 5000K) |
| Protection Class | IP66/IP67 |
| Cable Outside Diameter | φ8 – φ12 (Optional: φ10 – φ14) |
| Installation Method | Suspension Type |
| Ambient Temperature | -30℃ – +55℃ |
| Lamp Body Material | Engineering Plastics PC |
| Gland Material | Brass |
| Lamp Shade Material | Toughened Glass |
| Weight | 3.5kg |
Attention please: The description may be different with the product, please contact us for quotation.
