Marine Toilet Water Processor
Our SWCM(I) series Marine Toilet Water Processor System stands as a premier solution for the efficient and eco-friendly management of marine toilet wastewater, also known as black water, across a wide spectrum of marine vessels and offshore drilling platforms. This compact yet robust MBR (Membrane Bioreactor) system is meticulously engineered to not only meet but significantly exceed the rigorous IMO MEPC 227(64) standards for wastewater treatment, ensuring compliance with international maritime regulations. With a versatile range of 15 capacity options, from 15 to 400 persons, our system offers scalable and adaptable solutions tailored to the specific needs of ships of varying sizes, from small yachts to large cruise liners and offshore drilling rigs.
Key Features & Benefits:
✔ Specialized Black Water Treatment: Our system is exclusively designed to address the unique composition and challenges of marine toilet wastewater, providing effective and targeted treatment for optimal performance.
✔ Advanced MBR Technology: Utilizing cutting-edge 0.1μm membrane filtration, our system delivers unparalleled effluent quality, removing even the finest particles and impurities, ensuring crystal-clear treated water.
✔ Dual Air Pump System: This innovative feature optimizes aeration within the biological treatment tanks and facilitates efficient sludge transfer, enhancing overall treatment efficiency and reducing operational costs.
✔ UV Sterilization: Offering a chemical-free disinfection method, our system meets the strictest coliform standards, ensuring that the treated water is safe for discharge into the marine environment, protecting aquatic life.
✔ Global Certifications: Our system is certified by renowned marine classification societies, including ABS, BV, DNV, LR, USCG, and CCS, guaranteeing its compliance with international maritime regulations and standards.
✔ Versatile Application: While primarily designed for marine applications, our system is also suitable for treating terrestrial sewage, meeting national reuse water quality requirements. It can also handle greywater (galley and shower drainage) with pre-treatment and appropriate capacity selection.
Technical Specifications:
Model Range & Capacities:
| Model | Capacity (Persons) | Daily Flow (L) | Power (kW) | Dimensions (L×W×H mm) |
|---|---|---|---|---|
| SWCM(I)-15 | 15 | 1,190 | 2.5 | 1870×1200×1450 |
| SWCM(I)-50 | 50 | 3,780 | 3.0 | 2320×1700×1880 |
| SWCM(I)-100 | 100 | 7,700 | 4.0 | 2800×2100×2300 |
| SWCM(I)-200 | 200 | 14,700 | 6.0 | 3640×2250×2390 |
| SWCM(I)-400 | 400 | 30,800 | 11 | 5980×2450×2600 |
Additional Technical Data for Explosion-proof Drilling Platform Sewage Treatment Plant:
| Model | LOAD (L/d) | Rated Capacity (Men) | Max Capacity (Men) | External Dimension (mm) L×W×H | Dry Weight (kg) | Wet Weight (kg) |
|---|---|---|---|---|---|---|
| SWCM-10 | 840 | 10 | 15 | 1510×1200×1300 | 900 | 1775 |
| SWCM-15 | 1190 | 15 | 20 | 1870×1200×1400 | 1000 | 2283 |
| … | … | … | … | … | … | … |
| SWCM-400 | 30800 | 400 | 440 | 5950×2400×2570 | 4200 | 25417 |
Description for Explosion-proof Drilling Platform Sewage Treatment Plant:
Our explosion-proof drilling platform sewage treatment plant is designed to prevent pollution from ships and marine drilling platforms in accordance with the revised Annex IV of the International Convention for the Prevention of Pollution (MARPOL 73/78). This device is specifically engineered to treat sewage, including human body wastes and toilet wastewater (black water), to meet the effluent standards of IMO MEPC.159(55) and safely discharge the treated water overboard. The system adheres to the resolution MEPC.159(55) enacted on 13 October 2006, ensuring compliance with all relevant international regulations.
In addition to marine applications, our system is also suitable for treating terrestrial sewage, meeting national reuse water quality requirements. It can effectively handle greywater (galley and shower drainage) with pre-treatment, provided a larger capacity model is selected to match the increased load. Our system is certified by CCS, GL, ABS, DNV, BV, RS, and other classification societies, ensuring its reliability and compliance with global standards.
The device employs activated sludge, contact oxidation, and the principle of biological membranes to digest organic pollutants, providing efficient sewage treatment that meets or exceeds IMO’s new effluent standards and other stricter requirements.
Note: The description might be incorrect, please contact us for confirmation.
