MARINE MEDICAL CEILING LIGHT
Product Images and Installation Diagram
[The image shows the JPL41 medical ceiling light from multiple angles: a front – view photo, a side – view photo, and an installation diagram. The installation diagram includes detailed dimensions and a representation of how the light is mounted on the ceiling, with notes on the average illuminance and other related parameters.]
Applicable Scope
It is applicable to places with high cleanliness requirements in various medical operating rooms,无菌 (the original Chinese here, should be “sterile” in English context, so we use “sterile”) rooms, wards, and food processing workshops, such as operating rooms, sterile rooms, wards, food processing rooms, etc.
Technical Specifications
| Item | Detail |
|---|---|
| Type | JPL41 |
| Rated Voltage | AC220V 50/60Hz |
| Power | 40W |
| Power Factor | ≥0.95 |
| Illuminant | LED |
| Color | White |
| Luminous Flux | 4000lm (Optional: 3000K, 4000K, 5000K, 6500K) |
| Color Rendering Index | Ra≥90 |
| Color Temperature | 4000K (Optional values as above) |
| Average Illuminance | ≥1000lx (at a height of 2.8m) |
| Illuminance Uniformity | ≥0.7 |
| Installation Method | Ceiling – mounted Type (Flange – type or spring – type installation available) |
| Protection Class | IP65 |
| Ambient Temperature | -20℃ – +50℃ |
| Lamp Body Material | Stainless Steel 304/316 (Optional) |
| Lamp Shade Material | PC (Polycarbonate) with anti – ultraviolet and anti – aging treatment |
| Weight | 5.0kg |
Attention please: The description may be different with the product, please contact us for quotation.
