EXPLOSION PROOF INCANDESCENT PENDANT LIGHT
Main Parameters
| Item | Content |
|---|---|
| The scope of application | Suitable for illumination for possible accumulation of explosive gas mixtures of cabin or outdoor spaces. |
| Type | CFD1, CFD1-1, CFD1-2, CFD1-3 |
| Explosion-proof mark | ExdII CT4 Gb |
| Rated Voltage | DC24V, AC110V/220V |
| Power | ≤100W |
| Illuminant | Incandescent lamp |
| Lamp holder | E27 |
| Protection Class | IP56, IP67 |
| Cable outside diameter | φ10~φ12 |
| Ambient temperature | -25°C ~ +45°C |
| Lamp body material | High quality cast aluminum alloy (Aluminum alloy die-cast) |
| Lamp shade material | Tempered glass |
| Weight | 2.9KG, 4KG |
Diagram Specifications (Visual Data)
- H (Portable type): 390 mm height, Ø146 mm width.
- X (Ceiling type): 390 mm height, Ø146 mm width.
- Cable Entry: 4 x Ø11 EQB (for ceiling type).
- Top View Dimensions: 129 mm length, 110 mm width, Ø76 B175 center hole, 4 x Ø13.5 mounting holes.
- Bottom View Dimensions: Ø143 mm diameter.
Attention please: The description may be different with the product, please contact us for quotation.
