Heavy Duty 8000KGS Delta Welding HHP Anchor for Marine & Offshore Applications
Upgrade your vessel’s mooring system with Liwai Marine’s professional Delta Welding HHP (High Holding Power) Anchor. Engineered for superior performance and reliability, our HHP anchors are available in a wide weight range from 100 kg to 25,000 kg, making them suitable for various marine vessels and offshore structures.
Each anchor is manufactured from high-quality steel plate and casting steel (shank), ensuring exceptional strength and durability. Compliant with international marine standards, our Delta Welding HHP anchors are certified by leading classification societies including ABS, LR, BV, GL, KR, IRS, and CCS.
To guarantee weld integrity and structural soundness, every anchor undergoes rigorous magnetic particle examination after proof testing. From initial inquiry to final delivery, we are committed to providing high-quality products and seamless service tailored to your project requirements.
Delta Welding HHP Anchor – Specifications & Features
-
Material: High-Grade Steel Plate & Casting Steel (Shank)
-
Weight Range: 100 kg – 25,000 kg
-
Certifications: ABS, LR, BV, GL, KR, IRS, CCS
-
Design: High Holding Power (HHP), Ideal for All Ship Types
-
Quality Assurance: Magnetic Particle Inspection Performed Post-Welding
Anchor Weight & Dimensional Reference Table
| Weight (KG) | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) | F (mm) |
|---|---|---|---|---|---|---|
| 300 | 1200 | 960 | 1080 | 457 | 1380 | 45 |
| 500 | 1500 | 1200 | 1350 | 571 | 1725 | 50 |
| 1000 | 1875 | 1500 | 1686 | 714 | 2155 | 62 |
| 1080 | 1915 | 1530 | 1686 | 722 | 2200 | 62 |
| 2000 | 2363 | 1890 | 2124 | 900 | 2715 | 82 |
| 3000 | 2700 | 2160 | 2430 | 1028 | 3105 | 90 |
| 4000 | 2975 | 2380 | 2676 | 1133 | 3420 | 100 |
| 5000 | 3250 | 2600 | 2922 | 1238 | 3735 | 110 |
| 7000 | 3575 | 2860 | 3216 | 1361 | 4100 | 117 |
| 7500 | 3650 | 2925 | 3290 | 1390 | 4210 | 117 |
| 8000 | 3730 | 2900 | 3360 | 1420 | 4300 | 130 |
| 9000 | 3950 | 3160 | 3555 | 1504 | 4543 | 135 |
| 10000 | 4100 | 3280 | 3690 | 1561 | 4715 | 140 |
| 12000 | 4490 | 3575 | 4030 | 1695 | 5320 | 145 |
| 13500 | 4670 | 3720 | 4195 | 1765 | 5535 | 150 |
| 15000 | 4845 | 3875 | 4355 | 1830 | 5735 | 150 |
| 18000 | 5140 | 4080 | 4610 | 1940 | 6080 | 160 |
| 20000 | 5330 | 4260 | 4790 | 2010 | 6310 | 170 |
| 22500 | 5490 | 4360 | 4905 | 2060 | 6470 | 180 |
| 25000 | 5740 | 4590 | 5160 | 2165 | 6795 | 195 |
The description/sizes may be different with goods, please check with us when order.
