CSWG Series Marine Sewage Treatment Equipment
The CSWG series marine sewage treatment equipment is composed of three watertight boxes, namely a pretreatment cabinet, an anaerobic cabinet, and an oxidation treatment cabinet.
Through ingenious design of the control system and internal piping of the equipment, the CSWG series products achieve a unique multi-stage aerobic-anaerobic combined process mode in the industry (aerobic – anaerobic – aerobic), which ensures the best activity of bacteria and minimizes sludge production.
The equipment features an innovative modular design, making it more suitable for the layout of the engine room compared to general large-scale sewage treatment systems.
When the ship is in a situation where it cannot discharge sewage, the sewage can still circulate within the equipment for aerobic and anaerobic treatment processes, which is highly beneficial for peak treatment after leaving the port.
The CSWG series sewage treatment plant consists of three watertight boxes: pretreatment cabinet, anaerobic cabinet, and oxidation treatment cabinet. The ingenious internal pipeline design of the control system and equipment enables the CSWG series products to achieve the industry’s original multiple aerobic and anaerobic combination process mode (aerobic – anaerobic – aerobic), ensuring the best activity of bacteria and the minimum amount of sludge production. The ingenious modular design of the equipment is more suitable for the layout of the engine room than the general large sewage treatment system. When the port does not allow discharge, the sewage still circulates the aerobic and anaerobic process in the equipment, which has great benefits for the peak treatment after leaving the port.
Specifications Table
| Specification | Model |
|---|---|
| Parameter | CSWG-18 |
| Hydraulic Load (m³/d) | 18 |
| Organic Load (Kg/d) | 9 |
| Ambient Temperature Range / Ambient temperature range | 0 – 55°C |
| Inlet Operation Fluid Temperature / Inlet operating fluid temperature | 2 – 32°C |
Attention please: The description might be incorrect, please contact us for confirmation.
