Containerized Cable Winch | Complete Hydraulic Winch Package for Marine Research
This fully containerized cable winch represents a complete, ready-to-deploy hydraulic winch system engineered for advanced marine research applications. The integrated package includes a high-performance hydraulic power unit, precision electric control system, automatic spooling device, and slip ring transmitter specifically designed for single-core cable operations. Currently configured with a high-capacity coaxial single-core cable (Ø 11mm, approximately 5000m length), this system delivers exceptional performance for demanding research environments.
Key Features & Technical Specifications:
-
Complete Containerized Winch System: All-in-one solution with integrated hydraulic power unit and control systems
-
High-Capacity Cable Configuration: Equipped with 5000m coaxial single-core cable (Ø 11mm)
-
Precision Control System: Stepless speed regulation from 0-120 meters per minute
-
Superior Pulling Capacity: Maximum pull force of 30kN for demanding operations
-
Integrated Monitoring System: Real-time transmitters for cable length, speed, and pull force
-
Advanced Spooling Technology: Automatic spooling device ensures perfect cable layering
-
Versatile Research Applications: Ideal for CTD water sampling, video observation, sediment sampling, and research equipment towing
Research Applications & Capabilities:
-
CTD Water Sampling Profiling
-
Underwater Video Observation Systems
-
Marine Sediment Sampling Operations
-
Research Equipment Towing Applications
-
Oceanographic Data Collection
-
Marine Biological Research
Attention please: The description was copied from different cooperating manufacturers. The description may be different with the goods, please check with us when order.
