Triangle Mooring Chock – The Essential Heavy-Duty Mooring Solution
Built to Withstand Extreme Mooring Forces
As a critical component in vessel mooring systems, our Triangle Mooring Chock is engineered to handle massive loads during docking operations. These rugged cast steel chocks work in tandem with marine bollards to provide complete mooring security for vessels of all sizes.
Universal Application Across Marine Vessels
Our bulwark-mounted triangle chocks are the preferred choice for:
-
Small boats and work vessels
-
Commercial ships (container vessels, tankers, bulk carriers)
-
Service craft (tugs, supply vessels)
-
Dry cargo ships and specialized marine equipment
Parameters:
Nominal | Mass | Dimensions | ||||
Size | (kg) | (mm) | ||||
(mm) | A | B | C | D | E | |
348脳388 | 540 | 348 | 388 | 860 | 900 | 506 |
420脳440 | 640 | 420 | 440 | 730 | 800 | 560 |
430脳580 | 780 | 430 | 580 | 680 | 830 | 588 |
The description/sizes may be different with goods, please check with us when order.
