Swivel Fairlead – Premium Towing & Mooring Solutions for Marine Applications
Superior Rope Guidance for Demanding Operations
Our swivel fairlead provides unmatched performance for both wire ropes and marine fiber ropes, offering:
✔ Full Rotation Capability (180° or 360° options)
✔ Heavy-Duty Load Handling with certified SWL ratings
✔ Smooth Rope Movement reducing wear and friction
✔ Versatile Applications for towing ships and offshore vessels
Key Advantages Over Standard Fairleads:
• Superior Maneuverability: Swivel design accommodates multi-directional pulls
• Durable Construction: Marine-grade cast steel withstands harsh conditions
• Custom Sizing: Available in dimensions to match your specific requirements
• Proven Performance: Trusted by commercial fleets worldwide
Technical Specifications:
-
Material: High-strength cast steel
-
Rotation Options: 180° or 360° configurations
-
Load Capacity: Various SWL ratings available
-
Compatibility: Works with both wire and synthetic ropes
Parameters:
| Type | A(mm) | B(mm) | H(mm) | Φ(mm) | Max Wire Dia(mm) |
| SLPM20 | 400 | 425 | 350 | 250 | 20 |
| SLPM25 | 400 | 425 | 360 | 250 | 25 |
| SLPM32 | 600 | 600 | 376 | 320 | 32 |
| SLPM38 | 760 | 760 | 489 | 400 | 38 |
| SLPM44 | 880 | 880 | 580 | 500 | 44 |
| SLPM52 | 1120 | 1250 | 700 | 600 | 52 |
| SLPM60 | 1120 | 1350 | 720 | 620 | 60 |
| SLPM68 | 1210 | 1450 | 780 | 680 | 68 |
| SLPM76 | 1250 | 1500 | 870 | 780 | 76 |
The description/sizes may be different with goods, please check with us when order.
