Suez Canal Search Light
Product Image and Dimensions
The image shows the T25 Suez Canal search light from two perspectives: a front – view and a side – view with dimensional annotations indicating a diameter of approximately 780mm, a height of 548mm, and other relevant measurements such as 300mm for a particular part and a hole diameter of 4 – Φ19.
Main Technical Parameters
Scope of Application: Applied to illuminations of ships over 3000 S.G.T. pass through the Suez Canal and the narrow sea – route when night navigation, can search and illuminate the obstacle on the surface.
Product Specifications Table
| Specification | Detail |
|---|---|
| Type | T25 |
| Rated Voltage | AC110V/220V |
| Power | 2000W, 3000W |
| Illuminant | Tungsten halogen lamp |
| Shine Distance | 1500m, 1920m (corresponding to different powers probably, but not clearly specified which for which) |
| Lamp Holder | GY16/G38 |
| Luminous Flux | 53000/80000lm |
| Vertical Angle | (Not specified) |
| Adjustable Angle | Horizontal rotation ±180°, pitch ±30° (Rotate ±180° horizontally, pitch ±30°) |
| Protection Class | IP56 |
| Cable Outer Diameter | Φ12 – Φ14 |
| Installation Method | Base type |
| Ambient Temperature | -30°C ~ +55°C |
| Lamp Body Material | Aluminum alloy |
| Lamp Shade Material | Tempered glass |
| Weight | 87.1KG |
Attention please: The description may be different with the product, please contact us for quotation.
