Ship whistle WD Series Diaphragmatic Air Horn
The ship whistle WD Series Diaphragmatic Air Horn stands as a premier choice for boats, ships, and other marine vessels seeking a robust and reliable sound signaling device. This high-performance air horn is engineered to emit a loud, distinct, and far-reaching audible signal, ensuring effective communication with other vessels and timely warnings of potential hazards on the water.
Featuring a diaphragm crafted from top-quality, corrosion-resistant stainless steel, the WD series horn generates a powerful sound that cuts through ambient noise. Its adjustable valve empowers operators to fine-tune the volume and frequency of the sound, tailoring it to the specific needs of the vessel and the situation at hand. The horn’s body, constructed from a blend of stainless steel and brass, offers exceptional durability and resistance to saltwater and weather-induced corrosion. Designed for straightforward installation and maintenance, this compact horn requires only a source of compressed air to operate efficiently.
Compliant with international maritime regulations, including the International Regulations for Preventing Collisions at Sea (COLREGs), the WD series horn is suitable for a wide range of vessels, from commercial ships and pleasure craft to offshore platforms, ensuring adherence to all safety requirements.
Features:
- Powerful Sound Output: The WD Series Horn produces a loud and powerful sound that can be heard over long distances, making it an effective signaling device for marine communication and hazard warnings.
- High-Quality Construction: Made from corrosion-resistant stainless steel and brass, the horn ensures long-lasting durability and reliability in harsh marine environments.
- Adjustable Valve: The horn is equipped with an adjustable valve that allows operators to control the volume and frequency of the sound, providing flexibility in signaling.
- Easy Installation and Maintenance: Its simple and compact design facilitates easy installation and requires minimal maintenance, with only a compressed air source needed for operation.
- Compliance with International Regulations: The horn meets all safety requirements set forth by international maritime regulations, including COLREGs, ensuring its suitability for vessels of all sizes.
- Multiple Models Available: The ship whistle is available in various models, such as the WD-135 and WD-148, offering different sound output levels to cater to the diverse needs of different vessels and situations.
Scope of Application:
Ideal for medium and large ships, the Marine WD Series Diaphragmatic Air Horn is a versatile solution for enhancing maritime safety and communication.
Product Characteristics:
- High-Strength Copper and Aluminum Alloy Casting: Ensures robustness and longevity.
- Large Volume, Long Audible Distance, Low Air Consumption: Provides efficient and effective sound signaling.
Product Specifications:
| Type | Solenoid Valve Rated Voltage V(DC) | Solenoid Valve Power Consumption | Nominal Diameter | Preset Pressure (MPa) | Audible Distance | Sound Pressure Level (dB) | Frequency Range (Hz) | Weight (kg) |
|---|---|---|---|---|---|---|---|---|
| WD-1 | 220/110 | 45 | 25 | 10 (0.98) | >130 | 250~700 | 24 | |
| WD-2 | 220/110 | 45 | 25 | 10 (0.98) | >138 | 130~350 | 41 |
Additional Specifications for WD-1A, WD-2A, and WD-3A:
| Type | Voltage (AC/DC) | Nominal Diameter | Air Pressure (MPa) | Hearing Distance (m) | 1/3 Frequency Band (Hz) | Center Frequency (Hz) | Length of Ship (m) |
|---|---|---|---|---|---|---|---|
| WD-1A | AC110/AC220/DC110/DC220 | 25 | 7~10 (0.69~0.9) | ≥130 | 315 | ≥20 | <75 |
| WD-2A | ≥138 | 160 | ≥75 | <200 | |||
| WD-3A | ≥143 | 125 | ≥200 |
FAQs:
- Q: How does the adjustable valve on the WD Series Horn benefit operators?
- A: The adjustable valve allows operators to control the volume and frequency of the sound, enabling them to tailor the signal to the specific needs of the vessel and the situation, enhancing communication effectiveness.
- Q: What materials are used in the construction of the WD Series Horn?
- A: The WD Series Horn is constructed from high-quality, corrosion-resistant stainless steel and brass, ensuring durability and reliability in harsh marine environments.
- Q: Is the WD Series Horn compliant with international maritime regulations?
- A: Yes, the WD Series Horn complies with international maritime regulations, including COLREGs, ensuring its suitability for use on vessels of all sizes and adherence to safety requirements.
- Q: What are the different models of the WD Series Horn available, and how do they differ?
- A: The WD Series Horn is available in various models, such as the WD-135 and WD-148, which offer different sound output levels to cater to the diverse needs of different vessels and situations, providing flexibility in choosing the right horn for your specific application.
- Q: How easy is it to install and maintain the WD Series Horn?
- A: The WD Series Horn is designed for easy installation and maintenance, with a simple and compact design that requires only a source of compressed air to operate, making it a hassle-free solution for marine sound signaling.
Please Note: The description might be incorrect, please contact us for confirmation.
