Portable Self-Oscillating Fire Monitor
Our Portable Self Oscillating Fire Monitor is an intelligently engineered, mobile firefighting solution designed for rapid deployment and effective fire suppression. Controlled by an advanced PLC (Programmable Logic Controller) system, it offers fully adjustable self-oscillation within a 0 to 50-degree range, allowing operators to tailor water dispersion to specific fire conditions in real-time. The complete system includes the monitor body, oscillating head, intuitive control box, long-range remote, and portable charger—providing a versatile and reliable tool for emergency response teams.
Key Features:
-
PLC Intelligent Control System: Delivers precise, continuous adjustment of oscillation angle for optimized water coverage.
-
Long-Range Wireless Operation: Enables safe remote control from distances over 150 meters.
-
Self-Oscillating Water Dispersion: Ensines even and efficient water distribution across the fire area.
-
Portable and Mobile Design: Lightweight and easily transportable for rapid response scenarios.
-
Safe and Reliable Performance: Engineered for stability and durability under demanding conditions.
-
Dual Series Options: Available in water-only (PSKDY) and foam/water (PLKDY) models for various fire types.
Technical Specifications:
PSKDY Series (Water Monitor)
-
Models: PSKDY30 to PSKDY80
-
Flow Range: 30–80 L/S
-
Jetting Distance: ≥55–85 m
-
Working Pressure: 0.8–1.1 Mpa
-
Movement: Pitching angle +30° to +70°, Rotation ±90°
-
Voltage: 24V/DC
-
Remote Control Distance: ≥150 m
-
Weight: ≤30 kg
-
Connection: KY80 or KYK80 quick-connect
PLKDY Series (Foam/Water Monitor)
-
Models: PLKDY32 to PLKDY60
-
Flow Range (Water/Foam): 32–60 L/S | 48–70 m (foam)
-
Working Pressure: 0.8 Mpa
-
Movement: Pitching angle +30° to +70°, Rotation ±90°
-
Voltage: 24V/DC
-
Remote Control Distance: ≥150 m
-
Weight: ≤30 kg
-
Connection: KY80 or KYK80 quick-connect
Attention please: The description was copied from different cooperating manufacturers. The description may be different with the goods, please check with us when order.
