POLYPROPYLENE FILAMENT MULTIFILAMENT THREE STRAND ROPE
Product Description
- Material: Polypropylene Multifilament
- Density: 0.91g/cm³ (Floating)
- Melting Point: 165°C
- Elongation at Break: 19 – 21%
- Abrasion Resistance: Normal
- UV Resistance: Weak
- Chemical Resistance: Good
This rope is easy to handle, feels soft and smooth, and has good water – absorption, known as “Floating Nylon”.
Application: Marine mooring, sea farming, pelagic fishing.
Product Image
A coiled polypropylene filament three – strand rope is shown on the left side of the layout.
Parameter Table
| Diameter (mm) | Size (Circ.inch) | Weight (g/m) | Weight (kg/220m) | Breaking Strength (kN) | Breaking Strength (ton) |
|---|---|---|---|---|---|
| 4 | 1/2 | 6.3 | 1.39 | 2.3 | 0.23 |
| 6 | 3/4 | 18 | 3.96 | 6.5 | 0.66 |
| 8 | 1 | 32 | 7.04 | 11.4 | 1.16 |
| 10 | 1 – 1/4 | 47 | 10.34 | 16.8 | 1.71 |
| 12 | 1 – 1/2 | 68 | 14.96 | 23.9 | 2.44 |
| 14 | 1 – 3/4 | 95 | 20.90 | 32.9 | 3.36 |
| 16 | 2 | 121 | 26.62 | 40.7 | 4.15 |
| 18 | 2 – 1/4 | 155 | 34.10 | 51.9 | 5.30 |
| 20 | 2 – 1/2 | 189 | 41.58 | 62.6 | 6.39 |
| 22 | 2 – 3/4 | 231 | 50.82 | 75.0 | 7.65 |
| 24 | 3 | 273 | 60.06 | 87.7 | 8.95 |
| 26 | 3 – 1/4 | 320 | 70.40 | 101.0 | 10.31 |
| 28 | 3 – 1/2 | 373 | 82.06 | 115.0 | 11.73 |
| 30 | 3 – 3/4 | 425 | 93.50 | 132.0 | 13.47 |
| 32 | 4 | 483 | 106.26 | 146.0 | 14.90 |
| 36 | 4 – 1/2 | 614 | 135.08 | 182.0 | 18.57 |
| 40 | 5 | 756 | 166.32 | 221.0 | 22.55 |
| 44 | 5 – 1/2 | 924 | 203.28 | 266.0 | 27.14 |
| 48 | 6 | 1092 | 240.24 | 308.0 | 31.43 |
| 52 | 6 – 1/2 | 1281 | 281.82 | 357.0 | 36.43 |
| 56 | 7 | 1491 | 328.02 | 408.0 | 41.63 |
Other sizes are available upon request.
Attention please: The description may be different with the product, please contact us for quotation.
