Pear Shaped Shackle (Bow Shackle) – The Ultimate Load-Securing Solution
Engineered for Superior Load Distribution
✔ Optimized Shape Design – Wider rounded end for pin insertion and tapered tip for easy load attachment
✔ Enhanced Safety – Evenly distributes weight to prevent jamming and reduce stress points
✔ Heavy-Duty Performance – Forged/cast steel construction handles extreme rigging demands
✔ Versatile Compatibility – Works seamlessly with wire ropes, chains, and all lifting systems
Key Specifications:
-
Type: Pear-shaped shackle (Bow shackle)
-
Material Options: High-grade forged steel or cast steel
-
Strength Grades: U2 / U3
-
Surface Treatments: Black painted or hot-dip galvanized
-
Certifications: CCS, ABS, BV, LR, NK, RINA compliant
Pear Shaped Shackle Specification:
| L | B | W | C | D | D1 | D2 | R1 | R2 | Nominal Dia. (mm) | Proof Load (KN) | Breaking Load (KN) |
| 302 | 206 | 83 | 52 | 58 | 40 | 49 | 26 | 43 | 32~40 | 1411 | 1789 |
| 381 | 267 | 100 | 61 | 77 | 51 | 68 | 32 | 52 | 42~51 | 2243 | 2845 |
| 462 | 315 | 113 | 75 | 90 | 60 | 81 | 38 | 65 | 52~60 | 3049 | 3867 |
| 577 | 387 | 153 | 90 | 116 | 79 | 99 | 48 | 76 | 62~79 | 5080 | 6444 |
| 658 | 472 | 155 | 112 | 150 | 92 | 120 | 57 | 89 | 81~92 | 6699 | 8498 |
| 700 | 492 | 159 | 124 | 160 | 98 | 130 | 57 | 89 | 94~95 | 7096 | 9002 |
| 900 | 580 | 194 | 148 | 180 | 121 | 168 | 73 | 108 | 97~102 | 8055 | 10217 |
| 940 | 610 | 205 | 156 | 200 | 127 | 175 | 76 | 111 | 103~108 | 8195 | 10395 |
The description/sizes may be different with goods, please check with us when order.
