PARTIALLY ENCLOSED LIFEBOAT
PRODUCT DESCRIPTION
This partially enclosed lifeboat is used on cruise ships, ferry and Passenger Ferry. It can raise and load by gravity luffing arm type davit.
KEY FEATURES
- The rigid GRP canopy which the length is not less than 20% of boat is fitted both bow and stern.
- The folding canvas canopy is in the middle of the boat which can cover the wind and rain with the rigid GRP canopy both the bow and stern.
- High ornamental and can be used for cruise ships
- Fast embarkation
- Higher protection ability compared to the open type lifeboat
- As many kinds as Max. capacity of 150 persons lifeboat can be chose
PRODUCT SPECIFICATION TABLE 1
| Model | Dimension (m) | Person(p) | Hook Distance (m) | Total Height (m) | Total Weight (kg) |
|---|---|---|---|---|---|
| JY70P | 7.00×2.70×1.10 | 51 | 6.60 | 3.10 | 6628 |
| JY80P | 8.00×2.80×1.20 | 71 | 7.60 | 3.10 | 8400 |
| JY85P | 8.50×3.15×1.20 | 82 | 8.10 | 3.10 | 10120 |
| JY88P | 8.80×4.26×1.45 | 150 | 8.45 | 3.35 | 16800 |
| JY93P | 9.30×3.45×1.20 | 105 | 8.90 | 3.10 | 12850 |
| JY96P | 9.60×4.20×1.45 | 150 | 9.20 | 3.35 | 16800 |
PRODUCT SPECIFICATION TABLE 2
| Model | Dimension (m) | Person(p) | Hook Distance (m) | Total Height (m) | Total Weight (kg) |
|---|---|---|---|---|---|
| JY85PR | 8.50×3.85×1.20 | 150 | 8.20 | 3.65 | 15900 |
Note: The description may be different with the product, please contact us for quotation.
