Non-Spark Double Box End Wrench (Offset)

Non-Spark Double Box End Wrench

Place of Origin: Made In China
Delivery Time: 15-30 days
Click here to send inquiry via whatsapp

Category:

Non-Spark Double Box End Wrench (Offset)

Features: Used for tightening or loosening hexagon head bolts and nuts. The bent end is designed for use in confined spaces. Material: Aluminum Bronze/Beryllium Copper.

Number S(mm) L(mm) Weight(g) Be-Cu Al-Cu
1023-0607 6×7 115 60 ✓ ✓
1023-0810 8×10 120 75 ✓ ✓
1023-1012 10×12 135 90 ✓ ✓
1023-1214 12×14 135 95 ✓ ✓
1023-1415 14×15 150 110 ✓ ✓
1023-1417 14×17 155 120 ✓ ✓
1023-1618 16×18 170 130 ✓ ✓
1023-1719 17×19 170 140 ✓ ✓
1023-1922 19×22 190 170 ✓ ✓
1023-2224 22×24 220 210 ✓ ✓
1023-2427 24×27 230 240 ✓ ✓
1023-2730 27×30 250 300 ✓ ✓
1023-3032 30×32 270 360 ✓ ✓
1023-3236 32×36 300 480 ✓ ✓
1023-3441 34×36 295 460 ✓ ✓
1023-3841 38×41 340 610 ✓ ✓
1023-4146 41×46 370 820 ✓ ✓
1023-4650 46×50 400 1,000 ✓ ✓
1023-5055 50×55 420 1,100 ✓ ✓
1023-5560 55×60 480 1,500 ✓ ✓
1023-6065 60×65 500 1,700 ✓ ✓
1023-6570 65×70 530 1,850 ✓ ✓
1023-7075 70×75 570 2,300 ✓ ✓
1024 Non-Spark Flare Nut Ring Wrench

Features: Used for tightening or loosening pipe nuts. Can be used in tight spaces and areas where fittings are pre-assembled. Material: Aluminum Bronze/Beryllium Copper.

Number S(mm) L(mm) Weight(g) Be-Cu Al-Cu
1024-0607 6×7 115 70 ✓ ✓
1024-0810 8×10 130 85 ✓ ✓
1024-1012 10×12 140 100 ✓ ✓
1024-1214 12×14 140 110 ✓ ✓
1024-1415 14×15 150 120 ✓ ✓
1024-1417 14×17 160 130 ✓ ✓
1024-1618 16×18 170 140 ✓ ✓
1024-1719 17×19 180 150 ✓ ✓
1024-1922 19×22 200 180 ✓ ✓
1024-2224 22×24 220 240 ✓ ✓
1024-2427 24×27 240 300 ✓ ✓
1024-2730 27×30 270 370 ✓ ✓
1024-3032 30×32 290 480 ✓ ✓
1024-3236 32×36 300 500 ✓ ✓
1024-3441 34×36 330 580 ✓ ✓
1024-3841 38×41 350 680 ✓ ✓
1024-4146 41×46 380 950 ✓ ✓
1024-4650 46×50 420 1,200 ✓ ✓
1024-5055 50×55 460 1,300 ✓ ✓
1024-5560 55×60 500 1,600 ✓ ✓
1024-6065 60×65 540 1,700 ✓ ✓
1024-6570 65×70 570 2,050 ✓ ✓
1025 Non-Spark Double Box End Wrench (Offset)

Material: Beryllium Copper/Aluminum Bronze.

Number S(mm) L(mm) Weight(g) Be-Cu Al-Cu
1025-1719 17×19 180 180 ✓ ✓
1025-1922 19×22 200 240 ✓ ✓
1025-2224 22×24 220 300 ✓ ✓
1025-2427 24×27 240 340 ✓ ✓
1025-2730 27×30 270 400 ✓ ✓
1025-3032 30×32 290 480 ✓ ✓
1025-3236 32×36 300 540 ✓ ✓
1025-3441 34×36 340 600 ✓ ✓
1025-3841 38×41 360 700 ✓ ✓
1025-4146 41×46 400 920 ✓ ✓
1025-4650 46×50 430 1,200 ✓ ✓
1025-5055 50×55 480 1,350 ✓ ✓
1025-5560 55×60 520 1,550 ✓ ✓
1026 Non-Spark Double Flat Open End Wrench

Material: Aluminum Bronze/Beryllium Copper.

Number S(mm) L(mm) Weight(g) Be-Cu Al-Cu
1026-0810 8×10 115 65 ✓ ✓
1026-1012 10×12 135 70 ✓ ✓
1026-1214 12×14 135 80 ✓ ✓
1026-1417 14×17 150 90 ✓ ✓
1026-1618 16×18 160 110 ✓ ✓
1026-1719 17×19 175 120 ✓ ✓
1026-1922 19×22 200 140 ✓ ✓
1026-2224 22×24 220 180 ✓ ✓
1026-2427 24×27 240 230 ✓ ✓
1026-2730 27×30 260 280 ✓ ✓
1026-3032 30×32 280 330 ✓ ✓
1026-3236 32×36 300 360 ✓ ✓
1026-3441 34×36 320 400 ✓ ✓
1026-3841 38×41 340 490 ✓ ✓
1026-4146 41×46 380 580 ✓ ✓
1026-4650 46×50 400 630 ✓ ✓
1026-5055 50×55 440 760 ✓ ✓
1026-5560 55×60 480 880 ✓ ✓
1026-6065 60×65 500 970 ✓ ✓
1026-6570 65×70 540 1,200 ✓ ✓
1032 Non-Spark Single Open End Wrench

Features: Used for tightening or loosening large hexagon head bolts and nuts. Material: Beryllium Copper/Aluminum Bronze.

Number S(mm) L(mm) Weight(g) Be-Cu Al-Cu
1032-17 17 155 180 ✓ ✓
1032-19 19 165 210 ✓ ✓
1032-22 22 175 240 ✓ ✓
1032-24 24 175 260 ✓ ✓
1032-27 27 180 290 ✓ ✓
1032-30 30 190 340 ✓ ✓
1032-32 32 195 380 ✓ ✓
1032-36 36 215 520 ✓ ✓
1032-38 38 225 550 ✓ ✓
1032-41 41 235 650 ✓ ✓
1032-46 46 255 890 ✓ ✓
1032-50 50 265 1,080 ✓ ✓
1032-55 55 285 1,250 ✓ ✓
1032-60 60 310 1,550 ✓ ✓
1032-65 65 330 1,900 ✓ ✓
1032-70 70 350 2,250 ✓ ✓
1032-75 75 370 2,600 ✓ ✓
1032-80 80 380 3,000 ✓ ✓
1034 Non-Spark Striking Open End Wrench (Bent)

Features: Used for tightening or loosening large hexagon head bolts and nuts. Angle 45°, suitable for use in confined spaces. Material: Beryllium Copper/Aluminum Bronze.

Number S(mm) L(mm) Weight(g) Be-Cu Al-Cu
1034-24 24 180 340 ✓ ✓
1034-27 27 180 380 ✓ ✓
1034-30 30 190 430 ✓ ✓
1034-32 32 190 480 ✓ ✓
1034-36 36 210 680 ✓ ✓
1034-38 38 220 740 ✓ ✓
1034-41 41 240 870 ✓ ✓
1034-46 46 260 1,100 ✓ ✓
1034-50 50 270 1,350 ✓ ✓
1034-55 55 300 1,750 ✓ ✓
1034-60 60 330 1,950 ✓ ✓
1034-65 65 360 2,300 ✓ ✓
1034-70 70 380 2,900 ✓ ✓
1034-75 75 400 3,200 ✓ ✓
1034-80 80 430 3,500 ✓ ✓
1034-90 90 440 4,250 ✓ ✓
1034-100 100 480 5,600 ✓ ✓
1034-105 105 540 6,000 ✓ ✓
1035 Non-Spark Open End Wrench

Material: Beryllium Copper/Aluminum Bronze.

Number S(mm) L(mm) Weight(g) Be-Cu Al-Cu
1035-17 17 145 190 ✓ ✓
1035-19 19 145 210 ✓ ✓
1035-22 22 160 240 ✓ ✓
1035-24 24 165 260 ✓ ✓
1035-27 27 180 300 ✓ ✓
1035-30 30 190 360 ✓ ✓
1035-32 32 195 420 ✓ ✓
1035-36 36 215 510 ✓ ✓
1035-38 38 225 640 ✓ ✓
1035-41 41 235 740 ✓ ✓
1035-46 46 255 1,050 ✓ ✓
1035-50 50 265 1,250 ✓ ✓
1035-55 55 285 1,550 ✓ ✓
1035-60 60 310 1,850 ✓ ✓
1035-65 65 330 2,300 ✓ ✓
1035-70 70 350 2,750 ✓ ✓
1035-75 75 370 3,600 ✓ ✓
1035-80 80 380 4,200 ✓ ✓
1035-85 85 400 4,800 ✓ ✓
1035-90 90 430 5,200 ✓ ✓
1035-100 100 480 6,100 ✓ ✓
1035A American Type Non-Spark Open End Wrench

Material: Beryllium Copper/Aluminum Bronze.

Number S(mm) L(mm) Weight(g) Be-Cu Al-Cu
1035A-001 3/4 130 250 ✓ ✓
1035A-002 13/16 140 290 ✓ ✓
1035A-003 7/8 150 340 ✓ ✓
1035A-004 15/16 160 380 ✓ ✓
1035A-005 1 170 410 ✓ ✓
1035A-006 1-1/16 180 440 ✓ ✓
1035A-007 1-1/8 190 490 ✓ ✓
1035A-008 1-1/4 200 570 ✓ ✓
1035A-009 1-5/16 210 620 ✓ ✓
1035A-010 1-3/8 220 690 ✓ ✓
1035A-011 1-7/16 230 760 ✓ ✓
1035A-012 1-1/2 240 850 ✓ ✓
1035A-013 1-9/16 250 940 ✓ ✓
1035A-014 1-5/8 260 1,040 ✓ ✓
1035A-015 1-11/16 270 1,150 ✓ ✓
1035A-016 1-3/4 280 1,260 ✓ ✓
1035A-017 1-13/16 290 1,370 ✓ ✓
1035A-018 1-7/8 300 1,500 ✓ ✓
1035A-019 2 310 1,630 ✓ ✓
1036 Non-Spark Construction Wrench (Pin)

Features: Used for tightening or loosening large hexagon head bolts and nuts. With a pin on the handle. Material: Beryllium Copper/Aluminum Bronze.

Number S(mm) L(mm) Weight(g) Be-Cu Al-Cu
1036-17 17 145 210 ✓ ✓
1036-19 19 145 240 ✓ ✓
1036-22 22 160 280 ✓ ✓
1036-24 24 180 310 ✓ ✓
1036-27 27 210 360 ✓ ✓
1036-30 30 220 400 ✓ ✓
1036-32 32 230 440 ✓ ✓
1036-36 36 260 520 ✓ ✓
1036-38 38 270 590 ✓ ✓
1036-41 41 290 680 ✓ ✓
1036-46 46 320 840 ✓ ✓
1036-50 50 330 960 ✓ ✓
1036-55 55 360 1,200 ✓ ✓
1036-60 60 380 1,400 ✓ ✓

Note: The description may be different with the product, please contact us for quotation.
