Moorfast Anchor: High-Strength Mooring Solution for Demanding Marine Applications
The Moorfast Anchor is engineered for superior performance in permanent mooring systems, offshore installations, and heavy-duty marine operations. Built to withstand extreme environmental loads, this high-strength anchor delivers exceptional stability and reliability for critical marine infrastructure.
Precision-Engineered Design for Maximum Holding Capacity
Featuring an optimized geometric profile, the Moorfast Anchor ensures rapid seabed penetration and maintains consistent holding power across various soil conditions. Its robust construction makes it ideal for FPSO mooring, platform anchoring, and other permanent offshore applications where failure is not an option.
Technical Specifications & Performance Data
| Anchor Weight (lbs) | A (in) | B (in) | C (in) | D (in) | E (in) | F (in) | Proof Test (lbs) |
|---|---|---|---|---|---|---|---|
| 1,000 | 61 | 75 | 37 | 25 | 19 | 2 | 30,000 |
| 3,000 | 88 | 109 | 54 | 37 | 27 | 3 | 72,500 |
| 6,000 | 101 | 143 | 61 | 42 | 31 | 3 1/2 | 121,300 |
| 8,000 | 122 | 153 | 75 | 51 | 38 | 3 1/2 | 145,000 |
| 10,000 | 131 | 157 | 80 | 55 | 41 | 4 | 165,600 |
| 12,000 | 139 | 167 | 85 | 58 | 43 | 4 | 184,700 |
| 14,000 | 147 | 177 | 90 | 61 | 45 | 4 | 205,000 |
| 16,000 | 153 | 187 | 94 | 64 | 48 | 4 1/2 | 222,700 |
| 20,000 | 164 | 196 | 102 | 69 | 51 | 4 1/2 | 249,400 |
| 30,000 | 189 | 217 | 118 | 79 | 59 | 5 | 319,400 |
| 40,000 | 215 | 248 | 127 | 86 | 63 | 5 1/2 | 386,000 |
| 50,000 | 222 | 257 | 132 | 89 | 66 | 6 | 448,300 |
| 60,000 | 232 | 271 | 140 | 95 | 70 | 6 | 506,200 |
| 70,000 | 244 | 274 | 147 | 100 | 73 | 6 | 561,400 |
| 80,000 | 255 | 298 | 154 | 105 | 77 | 6 1/2 | 613,300 |
| 90,000 | 266 | 310 | 160 | 109 | 80 | 6 1/2 | 661,200 |
| 100,000 | 275 | 320 | 166 | 113 | 83 | 7 | 706,400 |
Key Features & Benefits:
-
Exceptional Weight Range: Available from 1,000 to 100,000 lbs to meet diverse project requirements
-
Rigorous Quality Testing: Each anchor undergoes proof load testing to verify structural integrity
-
Optimized Fluke Design: Ensures deep penetration and maintains consistent holding power
-
Permanent Mooring Specialist: Ideal for offshore platforms, floating structures, and heavy marine installations
-
Engineered Reliability: Designed for long-term performance in the most challenging marine environments
The description/sizes may be different with goods, please check with us when order.
