marine vertical centrifugal pump CL Series

Marine vertical centrifugal pump CL Series

General

CL Series marine vertical centrifugal pump are used at cabin bottom to cool water and fight fire. It is able to carry sea water under 80 degrees. Fresh water and other liquid medium.

The pump rotates anticlockwise viewed from the top of motor.

Main technical parameter

No.	Pump Model	Flow $m^{3} / h$	Head $m$	Speed $r / min$	NPSH $r (m)$	Shaft Power $kW$	Matching Motor Power $kW$
1	50CL-30	10 / 20 / 24	33 / 30 / 26	2950	4	3.4	4kW, Y112M-2-H
2	50CL-30A	9 / 18 / 21.6	26.8 / 24.5 / 21.3	2950	4	2.56	3kW, Y100L-2-H
3	65CL-45	15 / 30 / 36	49.5 / 45 / 39	2950	4	6.37	7.5kW, Y132S $_{2}$ -2-H
4	65CL-45	13.5 / 27 / 32.4	40.5 / 37 / 32	2950	4	4.32	5.5kW, Y132S $_{2}$ -2
5	80CL-30	25 / 50 / 60	33 / 30 / 26	2950	4.5	6.37	7.5kW, Y1132S $_{2}$ -2-H
6	80CL-30A	22.7 / 45.5 / 54.5	27.5 / 25 / 21.5	2950	4.5	4.48	5.5kW, Y132S $_{1}$ -2-H
7	100CL-30	50 / 100 / 120	33 / 30 / 26	2950	4.5	12.7	15kW, Y160M $_{1}$ -2-H
8	100CL-30A	45 / 90 / 108	26.8 / 24.5 / 21.3	2950	4.5	7.8	11kW, Y160M $_{1}$ -2-H
9	100CL-45	50 / 100 / 120	49.5 / 45 / 39	2950	5	18.7	22kW, Y180M $_{1}$ -2-H
10	100CL-45A	45 / 90 / 120	40 / 36.5 / 31.5	2950	5	12.6	15kW, Y160M $_{1}$ -2-H
11	150CL-30	80 / 162 / 194	33 / 30 / 26	2950	4.5	18.7	22kW, Y180M $_{1}$ -2-H
12	150CL-30A	74 / 148 / 177	27.5 / 25 / 21.5	2950	4.5	13.3	18.5KW, Y160L $_{1}$ -2-H
13	200CL-30	150 / 300 / 360	33 / 30 / 26	1450	5	31.45	37kW, Y225S $_{1}$ -4-H
14	200CL-30A	131 / 262 / 314	25.8 / 23.5 / 20.4	1450	5	21.2	30kW, Y200L $_{1}$ -4-H
15	200CL-30B	120 / 240 / 288	23.5 / 21.5 / 18.5	1450	5	17.5	22kW, Y180L $_{1}$ -4-H

Note: The description may be different with the product, please contact us for quotation.
