Marine Hydraulic Towing Pin for Shark Jaw
Our marine hydraulic towing pin stands as a top-tier stabilization component, meticulously engineered for seamless integration with shark jaw systems on anchor handling tugs (AHTs) and offshore support vessels (OSVs). This high-performance towing pin is specifically designed to mitigate the risks associated with dangerous chain and wire rope sway, thereby enhancing operational safety, preventing equipment damage, and boosting efficiency during critical marine towing, anchor handling, and mooring operations.
Key Features & Benefits for Enhanced Marine Operations
🔹 Superior Movement Control for Rough Seas: Our hydraulic towing pin effectively reduces side-to-side chain and wire rope swing by up to 70%, ensuring precise and safe handling even in the most challenging sea conditions. This feature is particularly beneficial for offshore vessel stabilization and anchor handling tug safety.
🔹 Hydraulic Remote Operation for Seamless Control: With smooth and reliable hydraulic actuation, our towing pin allows for effortless remote control from the vessel’s bridge or deck control station, enhancing operational flexibility and reducing manual intervention.
🔹 Retractable Design for Space Efficiency: The flush-mount design of our towing pin retracts completely when not in use, minimizing deck obstruction and optimizing workflow. This space-saving feature is ideal for crowded marine decks and ensures efficient use of available space.
🔹 Rapid Emergency Release for Enhanced Safety: In emergency situations, the integrated quick-release function of our towing pin enables immediate disengagement, significantly enhancing crew and vessel safety. This feature is crucial for preventing accidents and minimizing damage during unexpected events.
🔹 Rugged Marine Construction for Longevity: Manufactured from high-tensile steel with marine-grade corrosion-resistant finishes, our towing pin is built to withstand the harsh marine environment, ensuring extended service life and reliable performance.
🔹 Global Certification Compliance for Peace of Mind: Our towing pin is certified to meet ABS, BV, CCS, LR, DNV, and other major international marine classification society standards, providing assurance of quality and compliance with global regulations.
🔹 Flexible Configuration Options for Customization: Available in inclined (15° to 45°) or vertical mounting designs, our towing pin offers flexible configuration options to suit different vessel layouts and operational requirements, ensuring seamless integration and optimal performance.
150Ton Marine Ship Towing Pin for Shark Jaw: Precision and Safety Combined
Located at the forward side of the shark jaw, our 150Ton marine ship towing pin is designed to restrain the side-to-side movement of chain or wire rope while they are captured by the shark jaws during anchor handling operations. This feature makes anchor handling operations much easier and safer, reducing the risk of accidents and equipment damage.
Our shark jaw towing pin ensures that the chain or wire rope moves smoothly between them, preventing excessive swinging even when the vessel is towing other cargoes or changing direction. This not only enhances operational safety but also prevents outboard and wire rope breakage, further protecting your investment.
We offer towing pins with capacities ranging from 100T to 700T, with most models providing certificates such as ABS, BV, CCS, LR, GL, DNV, etc. For more information on our marine deck equipment towing pins, please don’t hesitate to contact us!
Technical Specifications
| Type | Bollard Pull | Holding Capacity | Power Required |
|---|---|---|---|
| TP-100 | 40ton | 100ton | 15kw |
| TP-200 | 60ton | 200ton | 22kw |
| TP-300 | 85ton | 300ton | 22kw |
| TP-400 | 120ton | 400ton | 30kw |
| TP-500 | 150ton | 500ton | 30kw |
| TP-700 | 200ton | 700ton | 37kw |
FAQs for Enhanced Understanding
- Q: How does the marine hydraulic towing pin improve operational safety during anchor handling?
- A: Our towing pin reduces side-to-side chain and wire rope swing by up to 70%, ensuring precise and safe handling even in rough sea conditions, thereby enhancing operational safety during anchor handling operations.
- Q: Can the towing pin be operated remotely?
- A: Yes, our towing pin features smooth and reliable hydraulic actuation, allowing for seamless remote control from the vessel’s bridge or deck control station.
- Q: What materials are used in the construction of the towing pin?
- A: Our towing pin is manufactured from high-tensile steel with marine-grade corrosion-resistant finishes, ensuring durability and longevity in harsh marine environments.
- Q: Does the towing pin comply with international marine classification society standards?
- A: Yes, our towing pin is certified to meet ABS, BV, CCS, LR, DNV, and other major international marine classification society standards, providing assurance of quality and compliance.
- Q: Can the towing pin be customized to suit different vessel layouts?
- A: Absolutely, our towing pin is available in inclined (15° to 45°) or vertical mounting designs, offering flexible configuration options to suit different vessel layouts and operational requirements.
Attention please: The description was copied from different cooperating manufacturers. The description may be different with the goods, please check with us when order.
