JIS F2006 Marine Open Chock – Secure & Durable Mooring Solution
Product Overview
The JIS F2006 Marine Open Chock is a high-performance marine component designed to safely guide mooring ropes while preventing damage and breakage. Available in two variants (Type FC and Type SC), this deck-mounted chock ensures optimal rope positioning and enhanced durability for smooth mooring operations.
Key Features & Benefits
✔ Dual Design Options – Choose between Type FC and Type SC to match your vessel’s mooring requirements.
✔ Premium Cast Steel Construction – Built for strength and corrosion resistance in harsh marine environments.
✔ Industry-Compliant – Manufactured to meet JIS F2006 standards for guaranteed reliability.
✔ Globally Certified – Approved by leading classification societies including CCS, ABS, BV, LR, NK, RINA, and more.
Parameters:
| Nominal size L (mm) | Calculated mass (kg) | L1 | a | B | b | B1 | H | h | h1 | l | l1 | l2 | l3 | R | R1 | r | r1 | r2 | r3 | t | t1 | t2 |
| 150 | 11.5 | 400 | 29 | 80 | 52 | 75 | 85 | 25 | 28 | 60 | 60 | 65 | 45 | 20 | 170 | 37.5 | 10 | 95 | 32 | 15 | 25 | 25 |
| 200 | 19 | 500 | 34 | 110 | 60.5 | 110 | 105 | 30 | 35 | 65 | 80 | 85 | 60 | 22 | 210 | 46.5 | 12 | 117 | 44 | 20 | 30 | 33 |
| 250 | 31.5 | 600 | 42 | 130 | 73 | 120 | 125 | 35 | 42 | 70 | 110 | 105 | 70 | 24 | 220 | 55.5 | 14 | 139 | 52 | 22 | 32 | 40 |
| 300 | 47 | 700 | 50 | 150 | 89.5 | 140 | 145 | 40 | 49 | 75 | 140 | 125 | 80 | 32 | 220 | 63.5 | 18 | 163 | 60 | 25 | 35 | 45 |
| 350 | 68 | 800 | 57 | 170 | 100 | 150 | 160 | 45 | 55 | 80 | 165 | 145 | 92.5 | 34 | 280 | 70 | 20 | 190 | 70 | 28 | 38 | 48 |
| 390 | 91 | 900 | 65 | 190 | 112 | 160 | 175 | 50 | 62 | 95 | 190 | 160 | 100 | 34 | 330 | 77.5 | 20 | 215 | 80 | 30 | 40 | 52 |
| 420 | 130 | 1000 | 79 | 210 | 131 | 190 | 195 | 55 | 67 | 100 | 210 | 190 | 105 | 34 | 380 | 86.5 | 22 | 240 | 90 | 32 | 42 | 55 |
The description/sizes may be different with goods, please check with us when order.
