Marine Oil Tank
Fuel System Oil Tank
Usage and Features
The fuel system oil tank is a device that stores fuel and sludge oil in one unit. It features a compact structure, occupies less space, is lightweight, and is convenient to operate. All external interfaces can be designed according to the layout requirements of the cabin pipelines to ensure convenient connection.
Specifications Table
| Model | Daily Oil Tank Volume | Sludge Oil Tank Volume | External Dimensions (mm) | |||||
|---|---|---|---|---|---|---|---|---|
| Daily Oil Tank | Sludge Oil Tank | |||||||
| L1 | B | H | L2 | B | H | |||
| JMYG2.5/1.0 | 2.5m³ | 1.0m³ | 1400 | 1400 | 1600 | 510 | 1400 | 1600 |
Small Boat Refueling Tank
Usage and Features
The small boat refueling tank is a storage and supply device for refueling ships’ small boats. Under normal circumstances, it draws diesel oil through a vane pump. When the flow rate is small, it can be switched to a hand pump to draw diesel oil via a three-way ball valve.
Specifications Table
| Model | Volume | External Dimensions (mm) | ||
|---|---|---|---|---|
| A | B | C | ||
| JMJYG0.7 | 0.7m³ | 1576 | 588 | 1685 |
Emergency Lubricating Oil Tank
Usage and Features
The emergency lubricating oil tank is a device for storing and supplying lubricating oil in emergency situations for the lubricating oil system.
Specifications Table
| Model | Volume | External Dimensions (mm) | ||
|---|---|---|---|---|
| L | B | H | ||
| JMHYG1.5 | 1.5m³ | 3354 | 1008 | 1534 |
Note: The description may be different with the product, please contact us for quotation.
