High-Efficiency Marine Oil Filter | Centrifugal Disc-Type Purification System
Our advanced Marine Oil Filter utilizes centrifugal force separation technology to effectively remove water, solid impurities, and contaminants from fuel and lubricating oils. Designed for marine diesel engines and industrial equipment, this system significantly reduces mechanical wear, extends engine life, and lowers operational costs by enabling the reuse of heavy diesel in place of light diesel.
Key Applications:
-
Purification of marine fuel oil and lubrication oil
-
Treatment of residual and distillate fuels
-
Clarification of mineral oils in chemical, pharmaceutical, and food industries
-
Turbine oil maintenance and recycling
Separation Performance Overview:
| Oil Type | Viscosity (MM/S) | Density (Kg/m³ at 20°C) | Separation Temp (°C) | Actual vs Rated Capacity |
|---|---|---|---|---|
| Distillate Fuel Oil | 1.9~5.5 | <900 | 20 | 130% |
| Residual Fuel | 5.5~24 | 900~991 | 40~98 | 25%~100% |
| High-Quality Lube Oil | 60~600 | 880~900 | 75~90 | 20%~85% |
How It Works:
The separator employs a high-speed rotating disc bowl where oil mixtures are subjected to intense centrifugal forces. Lighter oil is extracted through a paring disc and pump, while water and solids are ejected through separate outlets. This automated process ensures continuous operation with minimal manual intervention.
Design & Construction Features:
-
Robust Frame Assembly: Comprising lower, intermediate, and top sections with a protective hood.
-
Efficient Drive System: Electric motor with flat-belt transmission and overload-protection friction coupling.
-
Hydraulic Sludge Discharge: Automatically removes accumulated solids at set intervals.
-
Leak-Free Operation: Carefully balanced pressures and fluid levels prevent leakage during operation.
