Marine Oil Sludge Incinerator
Developed using Japanese-engineered technology and enhanced with global innovations, the WFS Series represents the next generation in sustainable waste disposal. Combining compact design with exceptional combustion efficiency, this system delivers eco-conscious performance with minimized harmful emissions – the optimal solution for hospitals, hotels, marine applications, and specialized waste treatment.
Key Advantages
✔ Gasification Pyrolysis Technology – Safely processes diverse waste types with superior thermal decomposition
✔ Daily Single-Batch Processing – Efficient gasification incineration enables complete daily waste cycles
✔ Triple-Phase Combustion System – Integrates gasification, mixed combustion, and burnout treatment to achieve:
-
Ultra-low emissions (dust, dioxins, etc.)
-
Full compliance with international environmental standards
✔ Closed-Loop Operation – 100% sealed processing prevents hazardous exposure, eliminating secondary pollution risks
✔ Space-Smart Engineering – Compact footprint maximizes efficiency in limited installations
Marine Incinerator Oil Sludge
Parameters:
| Model | WFS-30 | WFS-50 | WFS-150 | WFS-300 | WFS-500 |
| Burning Capacity | 20-30kg/time (3-6 times/day) | 30-50kg/time (3-6times/day) | 100-150kg/time (3-6times/day) | 200-300kg/time (3-6times/day) | 300-400kg/time(3-6times/day) |
| Combustion Improver Device | 0.11kw | 0.11kw | 0.11kw | 0.22kw | 0.22kw |
| Oil consumption: 4-6kg/h | Oil consumption: 4-10kg/h | Oil consumption: 4-10kg/h | Oil consumption: 7-14kg/h | Oil consumption: 7-14kg/h | |
| Re-Burning Device | 0.11 kw | 0.11kw | 0.22kw | 0.37kw | 0.37kw |
| Oil consumption 4-6 kg/h | Oil consumption: 4-10kg/h | Oil consumption: 7-14kg/h | Oil consumption: 10-20kg/h | Oil consumption: 15-26kg/h | |
| Incinerator Size m (L*H*B) | 1.45*0.9*1.75 | 1.8*1.15*3 | 2*1.4*3.5 | 2.2*1.4*3.8 | 3*2*4.8 |
| Imputing Mouth Width (mm) | 480*600 | 620*800 | 760*960 | 900*1100 | 1080*1280 |
| Chimney External Diameter | 280 | 280 | 300 | 400 | 460 |
| (mm) | |||||
| Draught Fan | 0.37kw | 0.37kw | 0.5kw | 1.1kw | 1.1kw/0.55kw |
| Voltage | 380v/220v | 380v/220v | 380v/220v | 380v/220v | 380v/220v |
The description/sizes may be different with goods, please check with us when order.
