JCL-42 Marine Fan
The JCL-42 Marine Fan is a high-performance centrifugal ventilation unit engineered for demanding marine and naval applications. Designed to handle harsh ocean environments, this fan efficiently moves air, salt-laden ocean vapor, and corrosive atmospheres containing oil vapors or mild acidic steam from battery evaporation. It is ideal for cabin air ventilation, air exchange systems, and boiler ventilation on ocean-going vessels, as well as other marine and industrial settings requiring durable, corrosion-resistant airflow solutions.
Key Features & Benefits
Compact & Lightweight Design: Space-saving construction simplifies installation and reduces structural load.
Exceptional Corrosion Resistance: Built to withstand saltwater vapor, oil fumes, and acidic environments.
Low Noise & Vibration: Optimized for quiet, smooth operation in crew cabins and sensitive areas.
High Airtight Integrity: Prevents leakage and ensures efficient airflow management.
Low Starting Torque: Reduces energy demand during startup for improved electrical efficiency.
Robust Durability: Engineered to resist swing, vibration, and shock in dynamic marine conditions.
Versatile Application: Suitable for vessel cabins, boiler rooms, naval ships, and offshore installations.
Technical Specifications
Model: JCL-42
Flow Rate: 5,500 – 14,000 m³/h
Total Pressure: 260 – 1,930 Pa
Static Pressure: 260 – 1,670 Pa
Speed: 970 – 1,750 r/min
Frequency: 50 Hz / 60 Hz
Motor Power: 2.2 – 11 kW
Motor Types: Y112M-6H, Y132M-4H, Y132S-6H, Y160M-4H
Dimensions & Installation Details
Mounting Options: Flexible installation with standardized flange connections (12-Ø12 mm / 4-Ø15 mm)
Key Dimensions: Customizable based on motor type; refer to detailed dimensional charts for specific values (A, B, D, L, H series parameters)
Weight: Approximately 100 – 178 kg (varies by motor configuration)
Note: The description might be incorrect, please contact us for confirmation.
