Marine Electric Switch Socket Application
Designed for naval and commercial vessels, this heavy-duty switch socket provides safe AC/DC low-voltage circuit control for marine electrical systems. It ensures reliable connection and disconnection of onboard appliances in demanding environments.
Construction & Durability
✔ High-Quality Cast Brass Shell – Robust and corrosion-resistant
✔ Acrylic Varnish Coating – Smooth finish with UV & weather resistance
✔ Mechanical Strength – Single-pole pullout force ≥4N
✔ Thermal Safety – Conductive part temperature rise ≤40K
Marine Electric Switch Socket Technical Parameters
| Feature | Specification |
| Type | CZKH2-2 |
| Protection Class | IP56 (Dustproof & Water-resistant) |
| Cable Compatibility | Ø14mm–16mm |
| Rated Voltage | 250V AC/DC |
| Rated Current | 16A (2P+E) |
Certifications & Standards
-
CE Certified – Meets EU safety requirements
-
CCS Approved – Compliant with China Classification Society
-
Marine Standard – CB 3412-1992
The description/sizes may be different with goods, please check with us when order.
