Barrel Mooring Marine Buoy
Introducing our high-performance Barrel Mooring Marine Buoy, an anti-typhoon anchor mooring buoy specifically designed for ship berthing and safeguarding naval vessels against typhoons at sea. This robust mooring system is tailored to accommodate vessels of varying tonnages, ensuring secure and flexible anchoring in diverse maritime conditions. Our mooring buoys are essential components of an effective anchor mooring system, providing convenience and reliability for ship mooring operations.
Composition of Anchorage Mooring Buoy:
- Floating Drum: Ensures buoyancy and stability.
- Mooring Ring: Facilitates secure attachment of anchor chains.
- Anchorage Block: Provides a solid foundation for the mooring system.
- Anchor Chains: Connects the buoy to the seabed anchor.
- Sinker: Enhances stability and prevents buoy drift.
Main Features:
- Constructed from Ship Steel: Ensures durability and strength in harsh marine environments.
- Filled with Resilient Closed-Cell Polyethylene Foam: Provides excellent buoyancy and impact resistance.
- Grit Blasted & Printed with Epoxy Paint: Enhances corrosion resistance and longevity.
- Compliant with China Sea Water Sign & General Technical Conditions of Buoys: Meets stringent industry standards.
- Welding Process in Accordance with China Classification Society Standards: Ensures high-quality welds and structural integrity.
- Passed Air Tightness Test Before Leaving Factory: Guarantees no leakage and reliable performance.
- Easy Installation: Simplifies setup and deployment in maritime settings.
- Long Service Life: Up to 8 years of reliable use.
- Excellent Impact Resistance & Anti-Settling Performance: Maintains stability and buoyancy in challenging conditions.
Types and Parameters of Mooring Buoy:
| Name | Buoyancy (Without Anchor Chains t) | Diameter × Height (m) | Anchor Chain (mm) | Mooring Ring (mm) | Sinker (t) | Cable Shackle (mm) | Mooring Capacity (t) |
|---|---|---|---|---|---|---|---|
| Type 2.0 Mooring Buoy | 3 | Φ2 × 1.74 | Φ62 | Φ45 | 4 | Φ90 | ＜2000 |
| Type 2.6 Mooring Buoy | 6 | Φ2.6 × 2.27 | Φ72 | Φ45 | 6 | Φ90 | ＜5000 |
| Type 3.6 Mooring Buoy | 9 | Φ3.6 × 2.14 | Φ90-Φ100 | Φ50 | 8 | Φ14 | ＜10000 |
| Type 5 Mooring Buoy | 28.5 | Φ5 × 3.4 | Φ122 | Φ60 | 12 | Φ14 | ＜12000 |
| Type 5.5 Mooring Buoy | 31.2 | Φ5.5 × 3.0 | – | – | – | – | ＜100000 |
| Type 6 Mooring Buoy | 34.2 | Φ6.0 × 3.2 | – | – | – | – | ＜150000 |
FAQs:
Q1: What makes the Barrel Mooring Marine Buoy suitable for anti-typhoon applications?
A1: The Barrel Mooring Marine Buoy is constructed from durable ship steel and filled with resilient closed-cell polyethylene foam, providing excellent impact resistance and buoyancy. Its design and materials ensure it can withstand the harsh conditions of typhoons, making it an ideal choice for ship berthing and typhoon avoidance.
Q2: Can the mooring buoys be customized to accommodate specific vessel tonnages?
A2: Yes, our mooring buoys come in various sizes and specifications, allowing us to customize them to accommodate vessels of different tonnages.
Q3: How do I install the Barrel Mooring Marine Buoy?
A3: The installation process is straightforward and easy. Our mooring buoys are designed for quick and secure deployment in maritime settings. We provide detailed installation instructions and support to ensure a smooth setup.
Q4: What is the expected service life of the mooring buoys?
A4: Our mooring buoys are built to last, with a service life of up to 8 years under normal conditions. Their robust construction and high-quality materials ensure long-term reliability and performance.
Q5: Are the mooring buoys compliant with international standards?
A5: Yes, our mooring buoys comply with stringent industry standards, including the China Sea Water Sign and General Technical Conditions of Buoys. Additionally, our welding process adheres to the relevant standards of the China Classification Society, ensuring high-quality welds and structural integrity.
Please Note: The description might be incorrect, please contact us for confirmation.
