A-Type Vertical Marine Air Receiver Tank
The A-Type Vertical Marine Air Receiver Tank is a robust, corrosion-resistant pressure vessel designed for efficient compressed air storage in marine, offshore, and industrial applications. Constructed with a high-grade steel body and equipped with a bottle valve assembly, this tank ensures safe, reliable operation under high-pressure conditions.
Its vertical cylindrical design includes a handhole (or manhole) for easy cleaning, inspection, and maintenance, while the bottle valve integrates inlet/outlet valves, safety valves, pressure gauges, drain valves, and mounting seats for complete system compatibility.
Certified for Marine & Industrial Safety
- Compliant with ISO 5840, ASME Section VIII, and marine classification standards (DNV, ABS, BV)
- Suitable for high-pressure air systems (1.0–3.0 MPa working pressure)
- Leak-proof construction ensures long-term durability in harsh marine environments
Key Applications
- Marine & Offshore:
- Engine starting air, control air systems, pneumatic tools, and emergency air reserves on ships, drilling rigs, and offshore platforms.
- Industrial Manufacturing:
- Powers pneumatic machinery, automation equipment, and process control systems in factories.
- Energy & Utilities:
- Acts as a compressor buffer tank and pulsation dampener in power plants and water treatment facilities.
Technical Specifications (A-Type Vertical Models)
| Style | Type | Capacity (m³) | W.P. (MPa) | Inner Dia (mm) | Height (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| A | A0.05-1.0 | 0.05 | 1.0 | 300 | 1050 | 70 |
| A | A0.10-1.0 | 0.10 | 1.0 | 400 | 1270 | 125 |
| A | A0.16-1.0 | 0.16 | 1.0 | 400 | 1750 | 155 |
| A | A0.25-1.0 | 0.25 | 1.0 | 500 | 1760 | 180 |
| A | A0.32-1.0 | 0.32 | 1.0 | 500 | 2170 | 248 |
| A | A0.40-1.0 | 0.40 | 1.0 | 600 | 1865 | 260 |
| A | A0.05-3.0 | 0.05 | 3.0 | 300 | 1050 | 100 |
| A | A0.08-3.0 | 0.08 | 3.0 | 300 | 1360 | 120 |
| A | A0.10-3.0 | 0.10 | 3.0 | 400 | 1270 | 165 |
| A | A0.16-3.0 | 0.16 | 3.0 | 400 | 1750 | 215 |
| A | A0.25-3.0 | 0.25 | 3.0 | 500 | 1760 | 195 |
| A | A0.32-3.0 | 0.32 | 3.0 | 500 | 2100 | 345 |
| A | A0.40-3.0 | 0.40 | 3.0 | 600 | 1865 | 410 |
| A | A0.50-3.0 | 0.50 | 3.0 | 600 | 2270 | 450 |
B-Type Horizontal Marine Air Receiver Tank | Large-Capacity Compressed Air Storage for Heavy-Duty Applications
The B-Type Horizontal Marine Air Receiver Tank is a high-capacity, industrial-grade pressure vessel engineered for large-scale compressed air storage in marine, offshore, and heavy industrial settings. Its horizontal cylindrical design includes a manhole for easy inspection and repair, while the steel body ensures durability under extreme pressure conditions.
Key Features
- Integrated valve assembly with inlet/outlet valves, safety valves, pressure gauges, drain valves, and mounting seats
- Corrosion-resistant construction for long-term reliability in saltwater environments
- Certified to ISO 5840, ASME, and marine standards (DNV, ABS, BV)
Main Applications
- Marine & Offshore:
- Bulk air storage for engine starting systems, pneumatic controls, and emergency air supplies on large vessels and offshore platforms.
- Industrial Manufacturing:
- Supports high-demand pneumatic systems in heavy machinery, assembly lines, and automation plants.
- Energy Sector:
- Acts as a compressor buffer tank in power generation stations and water treatment facilities.
Technical Specifications (B-Type Horizontal Models)
| Style | Type | Capacity (m³) | W.P. (MPa) | Inner Dia (mm) | Height (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| B | B0.63-1.0 | 0.63 | 1.0 | 700 | 1370 | 480 |
| B | B0.80-1.0 | 0.80 | 1.0 | 700 | 1370 | 520 |
| B | B1.00-1.0 | 1.00 | 1.0 | 800 | 1490 | 685 |
| B | B0.63-3.0 | 0.63 | 3.0 | 700 | 1470 | 680 |
| B | B0.80-3.0 | 0.80 | 3.0 | 700 | 1470 | 780 |
| B | B1.00-3.0 | 1.00 | 3.0 | 800 | 1580 | 950 |
| B | B1.60-3.0 | 1.60 | 3.0 | 900 | 1680 | 1180 |
| B | B2.50-3.0 | 2.50 | 3.0 | 1100 | 1940 | 1925 |
| B | B4.00-3.0 | 4.00 | 3.0 | 1200 | 2040 | 3400 |
| B | B4.50-3.0 | 4.50 | 3.0 | 1200 | 2040 | 3750 |
| B | B5.00-3.0 | 5.00 | 3.0 | 1200 | 2040 | 4100 |
| B | B6.30-3.0 | 6.30 | 3.0 | 1400 | 2265 | 4230 |
| B | B8.00-3.0 | 8.00 | 3.0 | 1500 | 2365 | 4930 |
| B | B10.00-3.0 | 10.00 | 3.0 | 1600 | 2505 | 6785 |
| B | B12.00-3.0 | 12.00 | 3.0 | 1700 | 2695 | 7500 |
| B | B14.00-3.0 | 14.00 | 3.0 | 1800 | 2750 | 8770 |
| B | B16.00-3.0 | 16.00 | 3.0 | 2000 | 3070 | 11000 |
Frequently Asked Questions (FAQs)
- What is the maximum working pressure for A-Type and B-Type air receivers?
- The A-Type supports 1.0–3.0 MPa, while the B-Type also operates at up to 3.0 MPa, depending on the model.
- Are these tanks suitable for marine applications?
- Yes, both are certified by DNV, ABS, and BV for marine safety compliance.
- How do I choose between vertical (A-Type) and horizontal (B-Type) tanks?
- Vertical tanks (A-Type) are ideal for limited floor space, while horizontal tanks (B-Type) offer higher capacity for large-scale storage.
- What maintenance is required for long-term performance?
- Regular pressure testing, inspection of safety valves, and cleaning via handhole/manhole are recommended.
- Can these tanks be used for drinking water systems?
- No, these are designed for compressed air storage only and are not food-grade certified.
