LONG D SHACKLE
• Material : SS Grade 304 / 316
| Code | Size | A | B | C | D | E | WLL(kg) | WT(kg) |
|---|---|---|---|---|---|---|---|---|
| ZB6411-4 | 4mm | 4.0 | 8.0 | 30.0 | 4.0 | 24.0 | 70.0 | 0.015 |
| ZB6411-5 | 5mm | 5.0 | 10.0 | 37.5 | 5.0 | 30.0 | 140.0 | 0.018 |
| ZB6411-6 | 6mm | 6.0 | 12.0 | 45.0 | 6.0 | 35.0 | 230.0 | 0.031 |
| ZB6411-8 | 8mm | 8.0 | 16.0 | 60.0 | 8.0 | 43.5 | 340.0 | 0.077 |
| ZB6411-10 | 10mm | 10.0 | 20.0 | 75.0 | 10.0 | 56.0 | 700.0 | 0.157 |
| ZB6411-12 | 12mm | 12.0 | 24.0 | 90.0 | 12.0 | 66.0 | 1200.0 | 0.251 |
Note: The description may be different with the product, please contact us for quotation.
