K Head Dock Bollard: The Ultimate Heavy-Duty Mooring Solution for Ports & Docks
Introducing our robust 100T K head Type Marine Mooring Dock Bollard, designed specifically for boats and wharfs. This high-capacity mooring bollard is a staple in port and dock operations, offering unparalleled strength and durability for warping applications of ships and vessels. As an economic and popular choice, the K-head marine bollard stands out among its peers, such as Y-type dock bollards, T-type bollards, S-type bollards, kidney-type bollards, and tee-head type bollards, which are also available upon request.
Key Features & Benefits:
- Versatile Sizes & Capacities: Our K-head marine wharf bollards come in a variety of sizes, with loading capacities ranging from 100T to 800T, catering to diverse mooring needs.
- High-Quality Materials: Constructed from durable materials like Cast Iron, Cast Steel, or Ductile Iron (Spheroidal Graphite), ensuring longevity and resistance to harsh marine environments.
- Corrosion-Resistant Mounting Hardware: Available with Galvanized Grade 8.8 bolts, nuts, and washers, or Stainless Steel options, providing excellent corrosion resistance.
- Superior Surface Finish: Shot Blast to Sa2.5 standard, then fully painted or treated with rust preventative primer for enhanced protection against the elements.
- Longevity & Warranty: Finished with good workmanship, our boat K-head bollards come with at least a 2-year warranty and an expected lifespan of 10 to 15 years.
Customization & Competitive Pricing:
We specialize in designing and producing marine boat bollards according to your specific drawings and technical requirements. Our commitment to quality ensures competitive pricing without compromising on the durability or performance of our products. With a strong presence in both domestic and overseas markets, we are eager to cooperate with you to create a bright future and mutual benefit.
Technical Parameters for K-head Type Marine Mooring Bollard:
| Marine Bollard | Nominal Dia (mm) | Weight (kg) | D (mm) | D1 (mm) | A (mm) | B (mm) | L (mm) | H (mm) | t3 (mm) |
|---|---|---|---|---|---|---|---|---|---|
| 100T | 114 | 19 | 145 | 10 | 250 | 165 | 445 | 196 | 6 |
| 125T | 140 | 29 | 180 | 10 | 315 | 195 | 540 | 246 | 6 |
| 160T | 168 | 45 | 210 | 10 | 400 | 225 | 670 | 316 | 6 |
| … | … | … | … | … | … | … | … | … | … |
| 800T | 813 | 3071 | 940 | 26 | 2000 | 1100 | 3240 | 1480 | 25 |
Additional Parameters for Different Capacities:
| Capacity (Tons) | Bolt Specification | A (mm) | B (mm) | C (mm) | D (mm) | E (mm) | F (mm) | G (mm) | H (mm) | I (mm) | J (mm) | K (mm) | L (mm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 15T | M24*4(500mm) | 40 | 260 | 340 | 320 | 320 | – | – | 220 | 160 | 160 | 160 | – |
| 30T | M30*4(500mm) | 40 | 280 | 370 | 360 | 360 | – | – | 260 | 200 | 180 | 180 | – |
| … | … | … | … | … | … | … | … | … | … | … | … | … | … |
| 200T | M56*7(1000mm) | 90 | 435 | 800 | 1000 | 850 | 300 | 300 | 750 | 450 | 475 | 375 | 50 |
Note: The description might be incorrect, please contact us for confirmation.
