Hydraulic Single Drum Winch – Precision Power for Heavy Load Handling
Product Overview
The Hydraulic Single Drum Winch is a high-performance deck machinery solution designed for mooring, towing, and heavy lifting operations. Featuring a friction drum for ultra-smooth load control and hydraulic-powered precision, this winch delivers reliable performance in the most demanding industrial and marine environments.
Key Applications
✔ Marine Operations: Vessel mooring, anchor handling, and cargo unloading
✔ Offshore Oil & Gas: Drilling rig positioning and equipment handling
✔ Construction & Mining: Heavy material transport and equipment relocation
✔ Port Operations: Barge handling and load management
Technical Specifications
Core Design Features
✔ Friction Drum System – Ensures stable, jerk-free load movement
✔ Hydraulic Power Unit – Delivers high torque with variable speed control
✔ Brake & Clutch Options – Manual or hydraulic systems for operational flexibility
✔ Robust Construction – Built to withstand saltwater, extreme temps, and heavy use
Performance Advantages
-
Precision Load Control – Infinitely adjustable speed for fine positioning
-
High Power Density – Hydraulic system provides greater force than electric winches
-
Safety-Certified Design – Automatic braking prevents uncontrolled movements
-
Low Maintenance – Durable components reduce servicing needs
Customization Options
-
Drum Capacity & Rope Length – Tailored to specific load requirements
-
Control Systems – Local lever control or remote operation
-
Special Configurations – Explosion-proof options for hazardous areas
Certifications & Compliance
✔ BV, LR, IRS – Certified to international marine and industrial standards
Parameters:
| Drum Capacity | Rated Speed | Motor Power | Rated Pull | |
| φmm*m | m/min | kW | T | kN |
| φ8*100 | ≥12 | — | 0.5 | 5 |
| φ10*150 | ≥12 | 5.5 | 1 | 10 |
| φ14*150 | ≥12 | 11 | 2 | 20 |
| φ16*150 | ≥15 | 15 | 3 | 30 |
| φ18*150 | ≥15 | 22 | 4 | 40 |
| φ20*200 | ≥15 | 30 | 5 | 50 |
| φ26*200 | ≥15 | 45 | 8 | 80 |
| φ28*200 | ≥15 | 55 | 10 | 100 |
| φ30*200 | ≥15 | 75 | 12.5 | 125 |
| φ32*250 | ≥15 | 75 | 16 | 160 |
| φ40*250 | ≥9.5 | 75 | 20 | 200 |
| φ44*250 | ≥9.5 | 90 | 25 | 250 |
| φ50*250 | ≥7.8 | 90 | 30 | 300 |
| φ56*250 | ≥7.8 | 110 | 40 | 400 |
| φ58*250 | ≥6 | 110 | 50 | 500 |
| φ64*250 | ≥5 | 132 | 60 | 600 |
The description/sizes may be different with goods, please check with us when order.
