Hatch Cover for Rope Hatch
Hatch Cover for Rope Hatch
CBM2013-81
Used for the rope hatch at the weather deck.
| Nominal size | Coaming D | Coaming t0 | H | Coaming D1 | Coaming t | Weight Kg | |
|---|---|---|---|---|---|---|---|
| H=450 | H=600 | ||||||
| Φ450 | 450 | 11 | 450 | 504 | 6 | 85.3 | 103.9 |
| Φ500 | 500 | 11 | 500 | 556 | 6 | 99.9 | 120.5 |
| Φ550 | 550 | 11 | 550 | 606 | 6 | 108.7 | 131.3 |
| Φ600 | 600 | 11 | 600 | 656 | 6 | 119.2 | 143.6 |
Note: Weight does not include part of coaming H1. H1 is determined by buyer.
Identification example
Nominal size Φ500mm, H=600mm hatch cover for rope hatch;
Hatch cover for rope hatch Φ500mm H=600mm CBM2013-81.
Note: The description may be different with the product, please contact us for quotation.
