Hall Anchors
Our Hall anchors are at the forefront of stockless anchor innovation, offering three distinct variants: Type A, Type B, and Type C. These anchors are meticulously crafted to adhere to international standards, ensuring top – notch quality and performance. They have earned the trust and certification of leading classification societies worldwide, including the American Bureau of Shipping (ABS), Lloyd’s Register (LR), Bureau Veritas (BV), Nippon Kaiji Kyokai (NK), Det Norske Veritas – Germanischer Lloyd (DNV – GL), Registro Italiano Navale (RINA), Korean Register (KR), Russian Maritime Register of Shipping (RS), and China Classification Society (CCS).
As a committed supplier in China, we are dedicated to delivering high – quality Hall anchors with reliable shipping services and professional customer support. Whether you need detailed specifications or custom – made anchors, our team is always ready to assist you. We are your reliable partner for all your stockless anchor needs.
Features
- Anchor Type: We offer Type A, Type B, and Type C Hall anchors, providing a range of options to suit different vessel requirements.
- Surface Treatment: Our standard surface treatment is black bitumen paint, which offers excellent anti – corrosion properties. Additionally, we can provide customized finishes to meet your specific aesthetic or functional needs.
- Packaging Options: To ensure the safe transportation of your Hall anchors, we offer various packaging choices, including carton, plywood case, plywood pallet, and nude packing.
- Certifications: Our Hall anchors are certified by multiple major classification societies, such as CCS, ABS, BV, LR, NK, RINA, and more, giving you peace of mind regarding their quality and compliance.
- Main Material: Made from high – grade cast steel ZG200 – 400C, our Hall anchors are durable and reliable, capable of withstanding harsh marine environments.
- Weight Range: We offer a wide weight range from 40kg to 46,000kg, with both standard and custom sizes available to meet your specific anchoring requirements.
Parameters
| Size(mm) | Nominal Weight |
|---|---|
| L | L1 |
| A | B |
| 430 | 303 |
| 492 | 347 |
| 584 | 410 |
| 629 | 443 |
| 670 | 470 |
| 710 | 500 |
| 784 | 552 |
| 844 | 595 |
| 910 | 632 |
| 946 | 660 |
| 1000 | 700 |
| 1042 | 732 |
| 1096 | 769 |
| 1170 | 820 |
| 1220 | 855 |
| 1260 | 885 |
| 1319 | 916 |
| 1374 | 965 |
| 1430 | 1001 |
| 1475 | 1035 |
| 1520 | 1070 |
| 1560 | 1104 |
| 1560 | 1120 |
| 1657 | 1165 |
| 1710 | 1200 |
| 1730 | 1222 |
| 1787 | 1253 |
| 1820 | 1275 |
| 1880 | 1317 |
| 1920 | 1345 |
| 1965 | 1376 |
| 2008 | 1406 |
| 2051 | 1435 |
| 2093 | 1465 |
| 2135 | 1498 |
| 2156 | 1510 |
| 2234 | 1569 |
| 2290 | 1610 |
| 2340 | 1644 |
| 2393 | 1681 |
| 2400 | 1688 |
| 2493 | 1752 |
| 2545 | 1788 |
| 2565 | 1800 |
| 2632 | 1850 |
| 2699 | 1896 |
| 2752 | 1934 |
| 2803 | 1970 |
| 2853 | 2005 |
| 2901 | 2039 |
| 2947 | 2072 |
| 2992 | 2104 |
| 3036 | 2135 |
| 3078 | 2165 |
| 3126 | 2199 |
| 3173 | 2232 |
| 3225 | 2268 |
| 3281 | 2308 |
| 3341 | 2350 |
| 3411 | 2399 |
| 3494 | 2458 |
| 3573 | 2514 |
| 3649 | 2568 |
| 3722 | 2619 |
| 3792 | 2668 |
| 3860 | 2716 |
| 3949 | 2774 |
| 4032 | 2833 |
| 4132 | 2903 |
| 4245 | 2982 |
| 4370 | 3070 |
| 4505 | 3165 |
Attention please: The description was copied from different cooperating manufacturers. The description may be different with the goods, please check with us when order.
