NS2585 Fairlead Roller
The NS2585 Fairlead Roller is engineered to safely direct mooring ropes while withstanding high breaking loads. Designed for reliability, it features:
✔ Compact & Robust Structure – Space-saving yet durable
✔ Smooth Surface Finish – Minimizes rope abrasion
✔ Stable Performance – Consistent operation in harsh marine conditions
✔ Custom Options – Tailored to unique vessel requirements
Key Features & Benefits
🔹 Model: NS2585 Fairlead Roller
🔹 Material: High-strength cast steel for longevity
🔹 Roller Diameter: 150mm–450mm (custom sizes available)
🔹 Rope Compatibility: Works with synthetic fiber ropes (32mm–80mm)
🔹 Standards: Compliant with NS2585 specifications
🔹 Certifications: Approved by CCS, ABS, BV, LR, NK, RINA, and more
Parameters:
| Dia. of Roller | Weight | Size | Max. Diameter of Applicable Rope | |||||||||
| (kg) | D1 | d0 | d7 | H | s | t | k | Synthetic Fiber | Hemp | Steel(GB1102) Rope Stress Length 1550N/mm² | ||
| Rope | Rope | 6×24 | 6×37 | |||||||||
| 150 | 24.8 | 240 | 90 | 79 | 154 | 5 | 12 | 9 | 32 | 45 | 17 | 15 |
| 200 | 49.3 | 310 | 115 | 99 | 186 | 5 | 14 | 10 | 40 | 55 | 22.5 | 19.5 |
| 250 | 92 | 380 | 135 | 119 | 230 | 6 | 14 | 10 | 45 | 65 | 24 | 24 |
| 300 | 127 | 440 | 155 | 129 | 255 | 7 | 16 | 12 | 50 | 70 | 30 | 28 |
| 350 | 168 | 500 | 175 | 149 | 271 | 7 | 18 | 13 | 55 | 75 | 37.5 | 34.5 |
| 400 | 252.5 | 560 | 185 | 159 | 307 | 7 | 20 | 14 | 65 | 85 | 41 | 39 |
| 450 | 310 | 630 | 210 | 178 | 316 | 7 | 20 | 14 | 80 | – | 44.5 | 43 |
Attention please: The description was copied from different cooperating manufacturers. The description may be different with the goods, please check with us when order.
