Marine EPR insulated shipboard power flexible cable
CEPJR/SC series, 6/10 kV
Example: CEPJR/SC 1×120
Type: CEPJR/SC
Application
Fixed installation for medium voltage (MV) power system in both EX-and safe areas, general purposes.
Standards applied
| Standard | Description |
|---|---|
| IEC 60092-354 | Design |
| IEC 60228 Class 2 | Conductor |
| IEC 60092-360 | Insulation |
| IEC 60092-360 | Sheath |
| IEC 60332-3-22 | Flame Retardant |
| IEC 60754 | Halogen Free |
| IEC 61034 | Low Smoke |
Construction
| Components | Code | Material/Description |
|---|---|---|
| Series code | C | Shipboard power cable |
| Conductor | – | Stranded tinned annealed copper (STC), IEC 60228 Class 5 |
| Conductor screen | – | Extruded semiconductive layer |
| Insulation | E | EPR, IEC 60092-360 |
| Insulation screen | – | Extruded semiconductive layer and having copper tape over it |
| Sheath | PJ | Halogen-free flame retardant thermoset compound (SHF2) |
| Construction | R | Flexible copper conductor |
| Outer sheath color | – | Black, if any |
| Flammability | SC | LSHF Flame retardant, IEC60332-3-22 (CAT.A) |
Note: The description may be different with the product, please contact us for quotation.
