Electric Single Drum Winch – Compact & Reliable Marine Handling Solution
Product Overview
Our Electric Single Drum Winch deliver powerful, precise load control for anchoring, mooring, and cargo operations. Featuring a streamlined single-drum design, it combines high strength with compact dimensions, making it ideal for vessels with space constraints. Available with 1-, 2-, or 3-speed electric motors and certified by BV, ABS, RINA, and other major classification societies.
Key Features & Benefits
✔ Compact & Lightweight – Space-saving design for easy installation
✔ Multi-Speed Control – 1/2/3-speed motor options for precise load management
✔ Durable Construction – Stainless steel / aluminum housing for corrosion resistance
✔ Flexible Operation – Local + remote control (wired/wireless)
✔ Safety Systems – Automatic brakes & overload protection
✔ Low Maintenance – Sealed bearings and easy-access lubrication points
Technical Specifications
| Parameter | Specification |
|---|---|
| Drum Type | Single drum (custom diameters) |
| Motor Options | 1-speed / 2-speed / 3-speed (explosion-proof available) |
| Load Capacity | 0.5–20 tons (higher capacities on request) |
| Control | Manual, hydraulic, or auto-tensioning |
| Certifications | BV, ABS, RINA, DNV, CCS (customizable) |
Parameters:
| Holding load | Nom.Speed | Drum load | Power | Rope dia. | |||
| Nylon | Wire Rope | ||||||
| T | kN | m/min | T | kN | kN | mm | mm |
| 15 | 150 | 15 | 5 | 50 | 16 | 45 | 20 |
| 24 | 240 | 15 | 8 | 80 | 25 | 50 | 26 |
| 31 | 310 | 15 | 10 | 100 | 32 | 55 | 28 |
| 36 | 360 | 15 | 12.5 | 125 | 38 | 64 | 30 |
| 48 | 480 | 15 | 16 | 160 | 50 | 75 | 38 |
| 63 | 630 | 15or12 | 20/25 | 200/250 | 61 | 90 | 40 |
The description/sizes may be different with goods, please check with us when order.
