Desalination System for Ships | Seawater to Drinking Water Generator for Ships & Offshore Use

Our Desalination System for Ships is a high-efficiency ship desalination system designed to convert seawater with salinity levels between 35,000–38,000 ppm into clean, safe drinking water that complies with WHO Drinking Water Standards (TDS ≤ 600 ppm). Ideal for marine and offshore applications, this system ensures reliable freshwater production even in challenging environments.

Built with durability and user-friendly operation in mind, the system includes a one-year warranty on core components—including membranes, high-pressure pumps, and piping—when operated in accordance with manual guidelines. It supports stable performance within an ambient temperature range of 0–45°C and seawater temperatures between 5–35°C.

Key System Features & Capabilities

  • Robust Pre-Treatment & Automation: Integrated raw water boosting, multi-stage filtration, semi-automatic cleaning, and compressed-air accelerated sand filter back-flushing.

  • Intelligent Monitoring & Safety Controls: Equipped with an online salinity monitor, over-pressure protection (auto-shutdown above 6.5 MPa), and low-pressure protection to prevent dry running.

  • Real-Time Performance Tracking: Monitor operating pressure, product/brine flow, and water conductivity for optimized system control.

Technical Specifications

  • Production Capacity: 15 m³/day

  • Feed Water Salinity: 35,000–38,000 ppm

  • Product Water TDS: ≤ 600 ppm

  • Desalination Rate: ≥ 98.5%

  • Recovery Rate: ≈ 28%

  • Inlet Water Temperature: 5–35°C

  • Power Supply: 440V AC / 60Hz / 3φ

  • Power Consumption: ≈ 6.6 kW (including boost pump)

  • Dimensions (L×W×H): 1350 × 650 × 1750 mm

  • Weight: Dry ≈ 650 kg | Wet ≈ 800 kg

Main Components Overview

  1. Low-Speed High-Pressure Plunger Pump

    • Capacity: 2 m³/h

    • Max Pressure: 55 bar

    • Power: 2.2 kW | IP55 Protection | Class F Insulation

    • Includes rubber dampers and marine-grade electric motor for quiet, reliable operation.

  2. Fiberglass Sand Filter

    • Removes suspended solids > 20 µm

    • Volume: 150 L | Max Flow: 2 m³/h

    • Semi-automatic valve enables efficient forward and backwashing.

  3. Dual-Stage Precision Filter

    • Includes 10µm and 5µm replaceable and washable filter candles.

    • Max Flow: 2 m³/h | Operating Pressure: 2–4 bar

  4. High-Quality RO Membranes by DOW (USA)

    • Model: SW30-2540 | Qty: 4

    • Type: Spiral Wound Composite Polyamide

    • Delivering superior salt rejection and long service life.

Certifications & Approvals
Our marine freshwater generators are certified by leading international classification societies, including:
ABS, BV, DNV, GL, KR, RINA, NK, USCG, and CCS.

The description/sizes may be different with goods, please check with us when order.
