DA Type (Super Arch) Rubber Fender – Superior Stability for Marine Docking
Engineered for exceptional performance in demanding marine environments, our DA Type Rubber Fender – also known as Super Arch Fenders – offer significant advantages over traditional arch designs. These advanced fenders provide enhanced structural stability and a more robust connection to supporting structures, ensuring reliable vessel protection during berthing and mooring operations. The innovative design distributes impact forces more effectively, making them an ideal choice for ports, docks, and terminals requiring maximum durability and safety.
Technical Specifications – DA Type Super Arch Fenders
| Model | B (mm) | b (mm) | c (mm) | d (mm) | H (mm) | h (mm) |
|---|---|---|---|---|---|---|
| SA-A200H | 400 | 320 | 145 | 128 | 200 | 30 |
| SA-A250H | 500 | 410 | 175 | 160 | 250 | 33 |
| SA-A300H | 600 | 490 | 225 | 196 | 300 | 33 |
| SA-A400H | 800 | 670 | 300 | 260 | 400 | 40 |
| SA-A500H | 1000 | 840 | 375 | 325 | 500 | 45 |
| SA-A600H | 1200 | 1010 | 450 | 390 | 600 | 54 |
| SA-A800H | 1600 | 1340 | 600 | 520 | 800 | 72 |
| SA-A1000H | 2000 | 1680 | 750 | 650 | 1000 | 90 |
The description/sizes may be different with goods, please check with us when order.
