Commercial Pipe Plug

Commercial series inflatable pipe plug can be constructed using high – quality natural rubber, NBR (Nitrile Butadiene Rubber), neoprene rubber, or other materials. Nylon layers are employed to reinforce them, ensuring that the inflatable pipe stoppers are resistant to fuel, petrochemicals, and other caustic chemicals. Each inflatable pipe plug is equipped with rigging hardware, inflation ports, and a pressure relief valve.

Specification Table

Model	Pipe Diameter (mm)	Air Pressure (MPA)	Diameter (mm)	Length (mm)	Weight (kg)
DN150 – 300	150 – 300	0.2	135	500	2.5
DN200 – 400	200 – 400	0.2	180	600	4
DN200 – 500	200 – 500	0.2	180	750	5
DN300 – 600	300 – 600	0.15	280	750	10
DN400 – 800	400 – 800	0.15	380	900	18
DN500 – 1000	500 – 1000	0.15	460	1050	25
