Commercial Heavy Duty Wire Rope Clip
Material: Body – Malleable Steel, U bolt – Q235 Carbon Steel
Surface Finish: Zinc Plated
| Size (mm) | d | A | H | Weight 100pcs (kg) |
|---|---|---|---|---|
| 6 | m6 | 13 | 31 | 0.038 |
| 8 | m8 | 17 | 41 | 0.075 |
| 10 | m10 | 21 | 51 | 0.130 |
| 12 | m12 | 25 | 62 | 0.200 |
| 15 | m15 | 29 | 70 | 0.320 |
| 18 | m16 | 35 | 87 | 0.420 |
| 20 | m16 | 37 | 92 | 0.490 |
| 22 | m20 | 43 | 108 | 0.720 |
| 25 | m25 | 46 | 113 | 0.980 |
| 28 | m28 | 51.5 | 127 | 1.460 |
| 32 | m32 | 55.5 | 136 | 1.650 |
-
d: Diameter of the wire rope
-
A: Cross-sectional area of the wire rope
-
H: Height of the wire rope
-
Weight 100pcs: Weight of 100 pieces of the wire rope
Note: The description may be different with the product, please contact us for quotation.
